Page 14 Instruction Manual GR100
SPECiFiCATiONS*
GeneraL
Complies with: as
Frequency Range: LW, MW, sW, VHF, aM and FM
Channel Set: Broadcast Radio Bands
Scan Speed: 100 ms/channel
Supply Voltage Range: 10 .8–15 .6 V DC negative earth
Current Protection: 2 a 3 aG fuse
Reverse Polarity &
Over Voltage Protection: ‘hi dc’ at 18 V shutdown at 21 V
reCeIVer
IF Frequencies: 1st: 10 .7 MHz, 2nd: 450 kHz
Modulation Frequency Response: 60 Hz–15 kHz for FM
Adjacent Channel Rejection: > 73 dB
Intermodulation Rejection: > 73 dB
Blocking Rejection: > 90 dB
Spurious Rejection: > 75 dB
Audio Output Power: 4 Watts x 2 average into external 4 Ohms
speaker . 2 Watts average into internal speaker .
Audio S/N: > 45 dB
Conducted Spurious Emission: < -70 dB
Current Consumption: Full Volume: 1 .2 a
SenSITIVITy
aM: -101 dBm 20 dB sINaD
FM: -101 dBm 30 dB sINaD
VHF: -105 dBm 12 dB sINaD
MeCHanICaL
Unit Dimensions: 164 (W) x 65 (H) x 58 (D) mm
Unit Weight: 360 g approx .
Flush Mounting Depth: 26 mm min .
enVIrOnMenTaL
Ingress Protection Rating: IP55 - Refer: www .gme .net .au/IPRatings/IPRatings .html
Temperature Range: -10°C to +60°C
Solar Radiation: Case uV stabilised
Compass Safe Distance: 200 mm
eXTernaL COnneCTIOnS
DC Supply: 2 Pin polarised plug socket
External Speaker: 3 .5 mm mini phone jack
*all specifications are typical and subject to change without notice or obligation.
