3
SQL Channel
Selector Liquid Crystal
Display
Volume
Control
Microphone
Port
Priority
Channel Key
Scan
Key
Duplex
Key
Squelch
Key
• Priority Channel: A user programmable
priority channel feature allows your working
or local repeater channel to be instantly
recalled at the press of a button.
• High Contrast Liquid Crystal Display:
Fully detailed LCD provides a visual
indication of the selected channel and all
selected functions at a glance. Backlit for
viewing at night.
• CTCSS: A built-in Continuous Tone Coded
Squelch System provides quiet channel
operation.
• Feature Disabling Function: Allows
Scanning, Squelch, Duplex, Priority and
CTCSS to be enabled or disabled to make
the radio simpler to operate.
• Overvoltage Protection: Special
overvoltage detection circuitry protects
the radio and warns of excessive voltage
conditions by flashing the display.
• Surface Mount Technology: The very
latest surface mount component types,
design and assembly techniques and
quality control procedures are used to
ensure the highest performance and
reliability.
• Designed and Manufactured in Australia:
The TX3200 has been totally designed and
manufactured in Gladesville NSW to meet
the demanding needs of the Australian
community.
OPERATION
VOLUME
Rotate the volume control clockwise past
the “click” to turn the TX3200 on. Adjust the
volume control for a comfortable listening level.
If no sound is heard, temporarily unmute the
radio by briefly pressing the
SQL key. You
can now adjust the volume by listening to the
receiver’s background noise. When finished,
briefly press the SQL key again to re-mute
the radio.
BACK LIGHTING
The Liquid Crystal Display and function keys
are backlit for easy viewing at night or in low
light situations. The back lighting is on at all
times while the TX3200 is turned on.
