general
Dc supply input: 11 – 16 Volts negative Ground
Power consumption: Approximately 10 W
transport stream: iso/iEc 13818
Profile & level: mPEG- mP @ ml
input frequency: VHF, uHF, 174 - 86 mHz
input impedance: 75 Ω unbalanced
coFDm spectrum: k and 8k mode
Guard interval: 1/3, 1/16, 1/8 and 1/4
Demodulation method: QPsK, 16QAm, 64QAm
Video resolution: 70 x 576 (PAl),
70 x 480 (ntsc)
Aspect ratio: 4:3, 16:9
audio
Audio decoding: mPEG-1 layers 1 and 11
Audio type: single channel, dual channel,
joint stereo, stereo.
Audio sampling rate: 3, 44.1 and 48 kHz
outputs
composite video output: x rcA
Audio: 4 x rcA
s-Video output: 1 x s-Video connector
physical
Dimensions: 370 mm (W) x 100 mm (H) x
35 mm (D)
Weight: Approximately 1.6 Kg
G t 9 6 0 0
i n s t r u c t i o n m A n uA l
PA G E 7
SpECiFiCATiONS
*all specifications are typical and subject to change without notice or obligation
TROUblESHOOTiNG
Does not display any
message at front panel
no video and no audio
Poor picture quality and
blocking error are displayed
remote control does
not operate
pROblEM
CHECK iTEM
check the main power is plugged into a suitable power outlet.
check the main power is on.
check antenna.
Based on signal level indicator in channel search menu adjust antenna position.
check if the cable/receiver and receiver/monitor are connected correctly.
change the antenna position. if antenna output is weak, connect to signal amplifier.
if antenna is small, change it to the bigger.
check battery.
make sure the remote sensor window is not under strong fluorescent lighting.
iNSTAllATiON
INFO
EN
TE
R
Extension infrared
Eye input
s-Video output
master
on/oFF switch
1 V Dc
input
remote Power
option for Antennas
x Audio/Video
outputs
Antenna
input 1
Antenna
input
remote control
