Chassis Device View
Port Icons
Device Views Cisco Catalyst 5000/5500 Hub
2-16 Management Module Guide
Port Table View
This view provides the following information:
Module
Displays the slot number in which this module is inserted in the chassis. Valid
entries are 1 to the maximum number of slots in this chassis.
Type
Displays the port type in terms of the medium it supports.
Speed
Displays the base speed of this port in bits per second.
Name
Displays the default model name for this module.
Index
Displays the port number.
Status
Displays the current status of this module.
Table 2-5 shows the possible
states:
Additional Status
Displays an integer representing additional information on the status of this
port.
Table 2-6 provides deÞnitions of the additional status values.
Table 2-5. Port Status DeÞnitions
Operational
Status
Administrative
Status
Text
Display
Color
ON ON ON Green
OFF OFF OFF Blue
OFF ON OFF Yellow
Testing Testing Test Red
Table 2-6. Additional Status DeÞnitions
Additional
Status Value
DeÞnition
0 Initial Value, or no activity was detected on the port in the last
polling period.
1 At least one packet was transmitted by the port in the last polling
period. No packets were received and no collisions were detected.
