Futaba GY611 User Manual

Page 24

ATA

ETTING

When Using a T14MZ Transmitter Gyro Mixing

The Gyro Mixing (Gyro) function lets operator perform three-point gain ad-

justment at each condition. Set the sensitivity at all conditions.

[GY611 Settings]

Select the gyro operation mode at the GY611 Mode screen. (AVC, NOR, or

CMT)

[Transmitter Settings]

End Point (ATV) function:

Adjust the both travels to 100% at the transmitter 3ch(Gyro) End Point func-

tion setup screen. (H-4 Swash: Sensitivity setting is assigned to 7ch.)

Gyro Mixing function:

1. Activate the function at the transmitter Gyro Mixing setup screen.

(If two or three rates are activated, select the selector switch.)

2. Set the type of gyro to GY.

3. Select the desired mode (AVCS or Nor) and adjust the gyro sensitivity by

rate.

(The following page shows a setting example in the CMT mode.)

[Sensitivity Display]

The gain display indicates the actual gain at the GY611 normal screen dis-

play. The following shows the relationship between transmitter and gyro set-

ting .

[Relationship between transmitter and gyro setting]

Transmitter settings: Nor AVCS

100% - 0% - 100%

Normal mode

AVCS mode

Normal mode AVCS mode

Actual gain: 100% - 0% - 100%

NOR:

AVC:

CMT:

GY611 mode

settings:
