GY611 control amp
Name and Function of Each Part
LCD contrast trimmer
· Allows adjustment of the contrast so that the LCD display is easiest to see.
It is adjusted with the accessory mini screwdriver.
(Receiver connectors)
Remote gain input
Rudder input
Edit keys
· Used when setting data.
Operated by pushing with
the accessory mini screw-
driver.
(Input/output terminals)
Gyro sensor input
Rudder servo output
GY611 gyro sensor
LCD display
· Displays the set data. (8 characters x 1 line)
· Stick to the body using the accessory
sensor tape.
· To control amp
