Futaba 12FG User Manual
Page 14
14
Volume
Volume LD and RD:
The volume LD and RD are analog type.
*T12FG beeps when the volume knob reaches center.
*You can use each setting screen of the mixing functions to
VHOHFWYROXPHVDQGGH¿QHWKHGLUHFWLRQRIDPRYHPHQW
Slide Lever
LS (Left), RS (right):
The slide lever LS and RS are analog type.
*T12Z beeps when the lever comes to the center.
*You can select a slide lever and set the movement direction
on the setting screen of mixing functions.
Digital Trim
This transmitter is equipped with six digital
trims. Each time you press a trim button, the trim
position moves one step. If you continue pressing it,
the trim position starts to move faster. In addition,
when the trim position returns to the center, the
tone will change. You can always monitor trim
positions by graphics on the screen.
To change the trim rate, you must activate this
through the function menu, within the linkage
menu. Use the EDIT dial to select the trim box and
then push the EDIT button and you will access
another screen which enables you to change the
trim percentages.
Note: The trim positions you have set will be stored in the
non-volatile memory and will remain there.
