5
BIND THE RECEIVER TO THE Tx
For proper operation it’s necessary to “bind” the Tx and Rx
together electronically. This ensures sole communication
between the two, and prevents other transmitters from being
able to control the receiver.
1. Turn on the Tx.
2. Apply power to the Rx.
3. If the Rx LED fl ashes once and then stays on, the
Rx is already bound to the Tx and you can skip to
the next section. Otherwise, insert a small diameter
screwdriver through the hole marked “BIND” and
press the pushbutton until the Rx LED glows red and
then turns off after about one second.
4. Release the “BIND” button.
5. If the binding is successful, the Rx LED will fl ash once
and then remain ON.
6. Test for proper Tx / Rx functionality in the next section.
If the radio doesn’t appear to have become properly
binded, repeat steps 1– 6 above.
FAILSAFE FUNCTION
The included TR624 receiver has a failsafe feature which
engages in the event that the radio signal from the transmitter
somehow becomes interrupted. This safety feature causes
the servos to automatically move either to a certain position,
or hold their last position so to prevent the model from moving
in an erratic manner. Channels 1, 2, and 4 will enter a “hold”
mode, whereby the servos will lock in their last recognized
position.
Channel 3 will move to a pre-set position. The factory default
failsafe position for channel 3 is to move to 0% full throttle.
Motor/prop movement should stop if the receiver loses signal
from the transmitter. The throttle servo’s failsafe position can
be manually re-set to any other position if desired, as follows:
IMPORTANT NOTE: Before manually resetting the
failsafe, make sure the servo reversing switches are in the
correct position for the application.
1. Apply power to the Tx and Rx.
2. If using an ESC, do NOT arm the ESC. Do NOT attempt
to adjust the throttle’s failsafe position if the ESC is
armed.
3. Move the Tx throttle stick to the desired position for the
throttle control to move if the Rx goes to failsafe.
4. Press and hold the “Bind” button on the receiver, and the
Rx’s LED should blink twice. Release the Bind button,
and the receiver’s LED should turn on (stop fl ashing).
The Tx and Rx should now be bound, with the throttle
failsafe in the new position as set above.
KIT INSPECTION
Before starting to build, take an inventory of this kit to make
sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not
of acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or missing
parts, use the part names exactly as they are written in the
Kit Contents list.
Hobbico Product Support Ph: (217) 398-8970 ext. 5
3002 N Apollo Drive Suite 1 Fax: (217) 398-7721
Champaign, IL 61822
E-mail: [email protected]
ORDERING REPLACEMENT PARTS
Replacement parts for the AcroWot MKII are available using
the order numbers in the Replacement Parts List that follows.
The fastest, most economical service can be provided by your
hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico web site at www.
hobbico.com. Select “Where to Buy” in the menu across the
top of the page and follow the instructions provided to locate
a U.S., Canadian or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721, but
full retail prices and shipping and handling charges will apply.
Illinois and Nevada residents will also be charged sales tax. If
ordering via fax, include a Visa
® or MasterCard ® number and
expiration date for payment.
Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822
Be certain to specify the order number exactly as listed in the
Replacement Parts List. Payment by credit card or personal
check only; no C.O.D.
If additional assistance is required for any reason contact
Product Support by e-mail at [email protected],
or by telephone at (217) 398-8970.
REPLACEMENT PARTS LIST
ORDER NO. DESCRIPTION
Fuselage Set
One Piece Wing
Vertical Fin
Horizontal Stab
Main Landing Gear
Tail Wheel Assembly
Spinner Assembly
Foam Battery Hatch
11x8 Propeller
Prop Adapter
Brushless Motor
40 Amp ESC
Hardware Set
Decal Sheet
GP 3S LiPo Balancing Smart Charger w/AC/DC
Tactic TTX404 4-Channel 2.4GHz Radio System
Tactic TT624 6-Channel 2.4GHz Receiver
LiPo Battery 3S 1800 mAh F L Z A 6 2 2 3
F L Z A 6 2 2 4
F L Z A 6 2 2 5
F L Z A 6 2 2 6
F L Z A 6 2 2 7
F L Z A 6 2 2 8
F L Z A 6 2 2 9
F L Z A 6 2 3 0
F L Z A 6 2 3 1
F L Z A 6 2 3 2
F L Z A 6 2 3 3
F L Z A 6 2 3 4
F L Z A 6 2 3 5
F L Z A 6 2 3 6
GPMM3318
TA C J 2 4 0 4
TA C L 0 6 2 4
F L Z A 6 0 2 4
