8
Install the prop saver adapter onto the motor shaft aligning
the screws with the fl at spots on the motor shaft. Be sure you
have the smallest diameter end of the prop saver towards the
front. Tighten the screws against the motor shaft.
Press the propeller onto the prop saver adapter. Hook a prop
saver o-ring onto one of the screw heads and pull the o-ring
over the prop hub onto the opposite screw head.
POWER THE TTX404 AND
CENTER THE TRIMS
TRIM ADJUSTMENT
Full extent............. Centered ........... Full extent
Constant «beep» .....Single «beep» ..... Constant «beep»
Illuminated red light indicates the
TTX404 is powered and transmitting.
Center the rudder, aileron,
and elevator trims.
Keep the left stick
(throttle control) in the
minimum throttle
position during setup.
Power switch “ON”.
CHECK THE CONTROL
SURFACE DIRECTIONS
Cut a piece from the hook side of the included hook and loop
material and stick it to the battery compartment as shown.
Cut a piece from the loop side of the hook and loop material
and stick it to the bottom of the battery.
