When Wet Cutting:
• Secure the drain plug and fill the tray with clean water.
On Gasoline Models:
GMS-20
•
Engage the water pump by loosening the pump
position lock, lower the water pump slide bracket and
retighten the pump position lock. (Figure 9)
• Prime the pump using the priming bulb. Pump the
bulb until water fills the clear plastic coolant hose from
the tray to the pump.
On Electric Models:
MS-14
•
Plug submersible pump into the special outlet on the
motor. (Figure 10)
This outlet is intended for the water
pump only. Do not use it for any
other purpose.
DO NOT LET THE
WATER PUMP RUN DRY.
Figure 10
On All Models:
• The water in the tray must be kept clean. Running
dirty water through the system will cause damage.
• To change the water, turn off the saw, remove the
plug in the bottom of the tray to drain water and
dispose of properly. Do not drain onto the surface
being worked on or other maintained surface because
staining will occur. Flush any loose grit and dirt out of
the tray. Replace drain plug and refill with clean
water. If water flow to the blade seems to be low,
check that strainer is clean and the water pump
pulley is properly engaged.
Figure 11
Figure 9
(Shows MS-20
Water Pump Plug)
Shows MS-14 Water Pump Outlet
