Propane
System
Main Fuel
Valve
Propane Tank
(20 lb horizontal)
Locating
Hole
NOTE: The Red arrow
on the tank will be point-
ing “up”. The locating
hole is oriented under
the gauge as viewed in
the photo on the left.
Propane Tank (P/N 5130)
Horizontal Mount (Vapor
Withdrawal)
#1 Main Power
Adjustment
High Pressure
LP Hose
Vacuum
Fuelock - Filter
High Pressure
LP Hose
Vacuum
Hose
Vapor Hose
(Low Pressure)
Dry-Gas
Regulator
#2 Idle Mixture
Screw
Propane Tank
(20 lb horizontal)
Fuel Gauge
Red Arrow
Pointing “Up”
Tank Bottom
