3.5 Adjusting the Paper Near-end Sensor
Move the paper near-end sensor lever to forward or backward. The position to
be set varies in accordance with the paper roll as shown in the following table.
CAUTION!
● Paper remainder (outside diameter of roll) differs by the type of paper roll used.
● The external diameter of the paper roll is only for reference.
● In the wall-mount status, you cannot use the paper near-end sensor.
Lever Position
External Diameter of Paper Poll Remainder
1
φ24
2
φ34
unit: mm
FEED
FEED
1
2
Lever
