Appendix A: VHSIM-G02 Specifications
A-2 VHSIM-G02 User’s Guide
A.3 GIGABIT PORT PIN ASSIGNMENTS
The following pin assignments are for the RJ45 Gigabit Ethernet ports on
the VHSIM-G02. The twisted pair ports conform to the IEEE 802.3ab
specification. The cables are 4-pair Category 5 UTP, up to 100 meters in
length.
Table A-4 RJ45 Port Pin Assignments
Pin Function
1 TRDA+
2 TRDA-
3 TRDB+
4 TRDC+
5 TRDC-
6 TRDB-
7 TRDD+
8 TRDD-
