Installing the VHSIM-G02
VHSIM-G02 User’s Guide 2-5
8. Press down firmly on the VHSIM-G02 until the connectors slide all
the way onto the pins. Ensure that the standoffs on the interface
module align with the standoff screw holes on the VHSIM-G02.
9. Secure the VHSIM-G02 to the module faceplate using the mounting
screws saved in step 5.
10. Secure the VHSIM-G02 to the module standoffs using the standoff
screws shipped with the VHSIM-G02.
11. Reinstall the interface module in the chassis.
12. Reattach the network cabling to the interface module.
2.2.2 Installing the VHSIM-G02 in a Standalone Device
To install a VHSIM-G02 into a standalone device (e.g., 2H252-25R) that
supports VHSIM technology, perform the following steps:
1. Power down the device and remove the power cord.
2. Note the ports that have cables attached to them. Write down the ports
and label the cables to make it easier to reattach the network properly
after the installation. Then disconnect the cables from the ports.
3. Attach the antistatic wrist strap (refer to the instructions outlined on
the antistatic wrist strap package).
4. Remove the standalone device chassis cover. Refer to your specific
standalone device documentation for instructions on removing the
chassis cover.
To install the VHSIM-G02 in a standalone device, the device
must first be powered down. Ensure that you remove the power
cord and ONLY the screws required to remove the chassis
cover.
!
CAUTION
The VHSIM-G02 and the device are sensitive to static
discharges. Use an antistatic wrist strap and observe all static
precautions during this procedure. Failure to do so could result
in damage to the VHSIM-G02 or device.
