Installing the VHSIM-G02
VHSIM-G02 User’s Guide 2-3
4. Lay the module down with the internal components facing up.
5. Refer to Figure 2-1 and remove the two faceplate mounting screws
and the VHSIM coverplate. Save the screws.
Figure 2-1 Removing the VHSIM Coverplate from the Host Platform
Faceplate Mounting Screws
VHSIM Coverplate
2549_03
Host Platform
