Chapter 2: Installation
2-6 VHSIM-G02 User’s Guide
5. Refer back to Figure 2-1 and remove the two faceplate mounting
screws and the VHSIM coverplate. Save the screws.
6. Refer back to Figure 2-2 and place the VHSIM-G02 module behind
the standalone device faceplate.
7. Align the VHSIM-G02 connectors with the pins on the standalone
device.
8. Press down firmly on the VHSIM-G02 until the connectors slide all
the way onto the pins. Ensure that the standoffs on the standalone
device align with the standoff screw holes on the VHSIM-G02.
9. Secure the VHSIM-G02 to the device faceplate using the mounting
screws saved in step 5.
10. Secure the VHSIM-G02 to the device standoffs using the standoff
screws shipped with the VHSIM-G02.
11. Reattach the chassis cover to the standalone device, reconnect the
power cord, and reconnect the standalone device to the network.
!
CAUTION
When inserting the VHSIM-G02 onto the device pins, ensure
that the pins do not bend, as this can damage both the device
and the VHSIM-G02.
Ensure that the chassis cover is in place before reconnecting
the power cord.
