Majestic Fireplaces
®
UVC / UVS Vent-Free Heaters
20000135
36"
34³⁄₄"
32³⁄₄"
5³⁄₄" 3¹⁄₄"
7³⁄₄"
2"
21"
1"
20"
9"
4"
33"
34¹⁄₄"
36"
36"
51"
25¹⁄₂"
Rough Opening Width 36¹⁄₂"
Finished Wall
Thickness
Gas Line
Access 2" Dia.
Electrical Cable
Knockout 1" Dia.
Electrical Box
Knockout 2" Dia.
Rough
Opening
Height
14¹⁄₂"
Rough
Opening
Depth
8¹⁄₂"
5¹⁄₂ "
Outside
Air
Electrical Cable
Knockout 1" Dia.
Gas Line Access 2" Dia.
0135
UVC/S36 Specs
9/7/00 djt
UVC/UVS36 Vent Free Room Heater
0135
Fig. 1 UVC/UVS36 specifications and framing.
UVC/UVS43 Vent Free Room Heater
0135
Fig. 2 UVC/UVS43 specifications and framing.
