-4-
2 .1 Supported Input formats and resolutions
The DVI-3551a accepts HDMI, DVI, Analog RGB, Analog Component Video,
S-Video (Y/C), and Composite Video inputs via rear-panel connectors. The
resolutions and formats supported by these inputs are as follows:
resolution / format
Vertical rate
(Hz)
Scan
format
Signal format
Input
Connector
NTSC/PAL SDTV 60 NTSC, 50 PAL Interlaced Composite Video RCA
NTSC/PAL SDTV 60 NTSC, 50 PAL Interlaced S-Video (Y/C) 4-pin mini-DIN
480i 720x480 60 Interlaced YUV NTSC RCA, HDMI (1)
576i 720x576 50 Interlaced YUV PAL RCA, HDMI (1)
480p 720x480 60 Progressive YPbPr / RGBHV (2) HD15, HDMI, RCA
576p 720x576 50 Progressive YPbPr / RGBHV (2) HD15, HDMI, RCA
720p 1280x720 50, 60 Progressive YPbPr / RGBHV (2) HD15, HDMI, RCA
1080i 1920x1080 50, 60 Interlaced YPbPr / RGBHV (2) HDMI, RCA
1080p 1920x1080 50, 60 Progressive YPbPr / RGBHV (2) HD15, HDMI, RCA
VGA 640x480 60, 72, 75, 85 Progressive RGBHV HD15, HDMI
SVGA 800x600 56, 60, 72, 75, 85 Progressive RGBHV HD15, HDMI
XGA 1024x768 60, 70, 75, 85 Progressive RGBHV HD15, HDMI
SXGA 1280x1024 60, 75, 85 Progressive RGBHV HD15, HDMI
UXGA 1600x1200 60 Progressive RGBHV HD15, HDMI
WXGA 1280x800 60 Progressive RGBHV HD15, HDMI
WSXGA 1680x1050 60 Progressive RGBHV HD15, HDMI
WUXGA 1920x1200 60 Progressive RGBHV HD15, HDMI
Note 1: This signal is actually 480i@30Hz doubled, or 576i@25Hz doubled.
Note 2: Analog YPbPr input is only available via the 3-RCA connectors, not via
the HD15-pin Connector.
