-3-
2 .0 SPeCIfICaTIonS
Input Connections
HDMI or DVI
1x HDMI female connector, DVI using DVI-8511b Adapter (not included)
Analog RGB 1x HD15-pin VGA female connector
Analog Component Video 3x RCA female connectors
S-Video 1x 4-pin Mini-DIN female connector
Composite Video 1x RCA female connector
Digital Audio (S/PDIF) 1x RCA female connector
Stereo Audio 6x RCA and 2x PC Audio (3.5mm)
Input formats
HDMI / DVI
HDMI v1.2 / HDCP 1.1 compliant (see table on page 4)
Analog RGB Up to 1920x1200@60 Hz, 1600x1200@60Hz
Analog Component Video YPbPr / YCbCr up to 1080p
Composite Video & S-Video (Y/C) NTSC / PAL formats
output formats
HDMI
1x HDMI female connector, HDMI v1.2 compliant
HDMI Output Resolutions Up to 1080p@60Hz and 1920x1200@60 Hz (see table on page 5)
HDMI Embedded Audio Digital audio per HDMI specification
Digital Coaxial Audio (S/PDIF) 1x RCA female connector
Audio Delay Adjustment OFF, 40 ms, 110 ms, 150 ms
Device Control
Front Panel
10x Buttons with On-Screen Display navigation
IR Remote Control IR Remote Control with On-Screen Display navigation
RS232 Control See tables on pages 11-14
Scaling engine
Phase Lock Loops
8-bit, Triple Analog to Digital Converter
De-Interlacing 3D Motion Adaptive De-Interlacing with 3D Noise Reduction
Pull-Down 3:2 with 2:2 recovery
Mechanical
Size (H x W x D)
1.9” x 8.5” x 6.1” (47.2 mm x 215.2 mm x 154.7 mm)
Weight (net) 2.2 lbs. (1.0 kg)
environmental
Operating Temperature
+32° to +122°F (0° to +50°C)
Storage Temperature +14° to +158°F (-10° to +70°C)
Operating / Storage Humidity 10% to 85%, Non-Condensing
Power requirements
AC Power Adapter
Input: 100-240VAC @50/60Hz Output: 5VDC @2.0A
regulatory approvals
Converter/Scaler Unit
FCC, CE, RoHS
AC Power Adapter FCC, CE, UL, CUL, PSE, GS, RoHS
accessories
Included Accessories
IR Remote Control Unit, AC Power Adapter, User Guide
Optional Accessories
International AC Power Adapter (USA, Euro, UK, Australia)
DVI-5300-RM Rack Mount Kit
