-3-
2.0 SPECIFICATIONS
Performance
Format Compliance
HDMI v1.2, HDCP v1.1 and DVI v1.0
Video Input Formats
Composite Video: NTSC or PAL
Component Video: YPbPr / YCbCr
HD15: Analog RGB,H,V
HDMI: Digital RGB
Maximum Pixel Clock Frequency 165 MHz
Maximum Video Bit Rate 1.65 Gbps (single-link)
Supported Color Depth 8-bit
Audio Input Formats
HDMI: embedded audio
Analog Stereo Audio: 20KΩ impedance
Audio Output Formats
HDMI: embedded audio
Analog Stereo Audio: 20KΩ impedance
Digital Audio (S/PDIF): 75Ω impedance
Audio Bandwidth 20 Hz to 20 kHz
Audio Sampling Rate 48 kHz, 2CH, LPCM
Audio Levels
Stereo Audio: unity, nominal
S/PDIF: 0.5 - 1.0 Vpp
Audio Delay Adjustment Off, 40ms, 110ms, 150ms
Input Connections
Composite Video Input
1x RCA female connector; Stereo Audio on 2x RCA female connectors
Component Video Input
1x 3x RCA female connectors;
Stereo Audio on 2x RCA female connectors
Analog RGB Input
3x HD15 (VGA) female connectors;
Stereo Audio on 3x 3.5mm PC audio female connectors
HDMI Input
3x HDMI 19-pin female connectors;
Stereo Audio on 3x 3.5mm PC audio female connectors
Power Input 1x Screw-locking 5.5 mm / 2.0 mm female connector
Output Connections
HDMI Output
2x HDMI 19-pin female connectors
Analog RGB Output 1x HD15 (VGA) female connector
Digital Audio Output 1x S/PDIF on RCA female connector
Analog Audio Output 1x Stereo Audio on 3.5mm PC audio female connector
Scaling Engine
Phase Lock Loops
8-bit, Triple-Analog-to-Digital Converter
De-Interlacing 3D Motion-Adaptive De-Interlacing
Pull-Down 3:2 with 2:2 recovery
Noise Reduction 3D
Display Settings
Contrast, Brightness, Hue, Sharpness, Saturation, R-G-B Levels,
Aspect Ratio, Noise Reduction
