Parts List
(1) DLE-55RA Gas Engine w/carb
(1) CM6 Spark Plug with spare ignition wire spring
(1) Muffl er w/gasket
(2) 5x20mm SHCS (muffl er mounting)
(1) Electronic Ignition Module w/ additional tachometer lead
(4) Engine Mounting Standoffs
(8) 5x20mm SHCS with 5mm washers (mounting engine to standoffs)
(4) 5x40mm SHCS with 5mm lock washers & fl at washers (propeller mounting)
(1) Silicone Pick-up Wire Cover / Ignition Wire Cover
(1) Red Three Pin Connector Lead w/ Pig Tail (ignition switch)
(2) Three Pin Connector Securing Clips
(1) DLE Decal
(2) 25 x75 mm White Exhaust Tubes with Clamps
Safety Tips and Warnings
● This engine is not a toy. Please place your safety and the
safety of others paramount while operating. DLE will not be
held responsible for any safety issues or accidents involving
this engine.
● Operate the engine in a properly ventilated area.
● Before starting the engine, please make sure all components
including the propeller and the engine mount are secure and tight. It
is strongly recommended that a screw sealant is used (Great Planes
®
Threadlocker GPMR6060) during engine installation.
● During the break-in period, it is recommended that the engine be
installed on the aircraft or a test stand with an appropriate shock
absorber. Otherwise it is probable that vibration could rebound
