39
DAC-530E-EN-BH
6 DDU-120 AED Accessories
This chapter describes the components and accessories that can be used with the Defibtech
DDU-120 AED. Information on obtaining replacement components and accessories is included
in the “Contacts” section.
6.1 Defibrillation/Monitoring Pads
The DDU-120 AED is used with Defibtech self-adhesive
defibrillation/monitoring pads for adults or with attenuated
pediatric pads for infants and children. These pads (also
known as “electrodes”) serve two functions:
• Allow the unit to read the patient’s electrocardiograph
(ECG) rhythm.
• Deliver defibrillation energy to the patient when
needed.
The Defibtech self-adhesive defibrillation/monitoring pad
assembly comes in a “leads-out” sealed package that allows
the device to be stored with pads connected. When the
DDU-120 AED is used, the operator needs only to remove
the pad packaging, tear open the package and turn the device
on to administer care. The AED has a storage area in the
back of the unit that allows for storage of a single sealed pad
package.
6.2 Battery Packs
The Defibtech AED uses a lithium battery pack. The battery
pack contains the main lithium battery cells, an LED status
indicator, and a 9V lithium battery. Different capacity battery
packs are available. Refer to the “Battery Packs” section for
detailed information on the available packs. The battery pack is
inserted into the battery pack opening on the side of the AED
and latches into place.
