SOURCE | 5
Source: Front Panel Features & Benefits
1. HEADPHONE OUTPUTS
[
headphone source section pictured above
]
Feature: Headphone jack 1 & 2 sport a potent headphone amplifier.
Benefit: Loads of
headroom
, to audition intelligibly, make intelligent decisions and drive an inspired performance. Please exhibit
caution when selecting a level. (See “
tip
”)
Operation: First choose a source to monitor from, by depressing the appropriate
headphone source
button. Then determine a
moderate listening level via the
headphone level
knob.
Tip:
,
Always start with the level control completely counter clockwise (minimum). The headphone amplifiers are very
powerful and there is no solution for destroyed hearing, even from the audio alchemists at Dangerous Music.
2. HEADPHONE SOURCE (TOGGLE & LATCH MODE)
[
headphone source selector pictured above
]
TOGGLE
Feature: Instantly and silently switch between four headphone input sources (
analog 1
,
analog 2
,
aes / spdif
and
usb
).
Benefit: While mixing, flip between a reference track. For example, CD source or iPod connected via analog
input one
or
input two
and your mix connected digitally via
usb
or
aes
/
spdif
.
Note: This is the default setup.
LATCH
Feature: Silently select or deselect any combination of 1, 2, 3 or 4 headphone sources (i.e.
analog 1
,
analog 2
,
aes / spdif
and
usb
).
Benefit: Monitor multiple audio inputs simultaneously. For example, feed the master mix into the
usb
input and the talent (i.e.
vocalist singing now) into
analog 1
for zero latency monitoring. (See
appendix
for more examples from DJ’s to Producers).
Note: Requires
setup
. See the following section for details.
Tip:
,
Headphone sources and Speakers sources are completely independent. (i.e. listen to different things from each).
