15
SPECIFICATIONS
D.A.S. Audio S.A. continuously strives to enhance its products through investigation and development. All specifications are subject to change without
prior warning.
Product specifications, detailed technical sheets, as well as information for the use of EASE and other modelling programs are available at
. www.dasaudio.com
Notes: 1. Continuous power at driver impedance.
2. Level Control at maximum.
3. Measured maximum peak level.
avant 118A
1250W (D)
---
Balanced Line
Line: 20kohms
Line: 1.95V (+8dBu)
Loud: 50 Hz - 142 Hz
Deep: 45 Hz - 138 Hz
---
Plywood
Black paint
LF: 18LX/ GM 18LX
2 x Female XLR
2 x Male XLR
AC INPUT: PowerCon NAC 3FCA
AC OUTPUT: PowerCon NAC 3FCB
84 x 60 x 65.5 cm
(33 x 23.6 x 25.8 in)
55 kg (121 lb)
TRD-6
Model
avant 12A avant 15A avant 215A avant 18A
1 LF Power Amplifier 500 W (D) 500 W (D) 500 W (D) 750 W (D)
1 HF Power Amplifier 100 W (D) 100 W (D) 100 W (D) ---
Input Type Balanced Line Balanced Line Balanced Line Balanced Line
Input Impedance Line: 20kohms
Mic: 20kohms
Line: 20kohms
Mic: 20kohms
Line: 20kohms
Mic: 20kohms
Line: 20kohms
2 Sensitivity Line: 1.95V (+8 dBu)
Mic: 20 mV (-32 dBu)
Line: 1.95V (+8 dBu)
Mic: 20 mV (-32 dBu)
Line: 1.95V (+8 dBu)
Mic: 20 mV (-32dBu) Line: 1.95V (+8dBu)
Frequency Range (-10 dB) 60 Hz - 20 kHz
(EQ main)
45 Hz – 20 kHz
(EQ flat)
40 Hz – 20 kHz
(EQ flat)
35 Hz – 160 Hz
(variable X-over)
3 Maximum Peak SPL at 1 m 133 dB 133 dB 136 dB 133 dB 136 dB
HF Horn Coverage Angles (-6dB) 80º x 50º
(Rotatable)
80º x 50º
(Rotatable)
80º x 50º
(Rotatable)
---
Enclosure Material Plywood Plywood Plywood
Finish/Color Black paint Black paint Black paint Black paint
Transducers/Replacement Parts LF: 12AV4/ GM 12P4
HF: M-50N/ GM M-50
LF: 15AV4/ GM 15P4
HF: M-50N/ GM M-50
LF: 15AV/ GM 15P
HF: M-50N/ GM M-50
LF: 18H/ GM 18G
Connectors INPUT
LOOP THRU
AC INPUT
Female XLR-Jack
Male XLR
Male IEC
Female XLR-Jack
Male XLR
Male IEC
Female XLR-Jack
Male XLR
Male IEC
2 x Female XLR
2 x Male XLR
Male IEC
Dimensions (H x W x D) 71.3 x 36.2 x 39.7 cm
( 28 x 14.3 x 15.6 in)
83 x 44.8 47.6 cm
( 32.7 x 17.6 x 18.7 in)
121 x 44.8 x 47.6 cm
( 47.6 x 17.6 x 18.7 in)
63 x 54 x 65 cm
(24.8 x 21.3 x 25.6 in)
Weight 22 kg (48 lb) 30 kg (66 lb) 44 kg (96.8 lb) 39 kg (85.8 lb)
Accessories ANL-5
TRD-5
TRD-2
ANL-5
TRD-5
TRD-2
ANL-5 TRD-5
Plywood
