) INPUT :
1/4” Jack+XLR c
:
1 or S =GND (ground).
2 or T =(+) Non inverted input.
3 or R =(-) Inverted input.
) LOOP THRU :
XLR-type output signal connector for connecting several units together and sending them all the same
signal.
) LIMIT :
Red LED indicates amplifier saturation. Amplifier limiter indicator lights.
) SIGNAL :
Green LED indicates signal presence.
) ON :
Green LED indicates that the unit is ON (other blue LED at the unit front indicates ON).
) LEVEL :
Potentiometer for adjusting the unit level.
) BOOST/FLAT :
Button for switching between two types of frequency response (see graphs). Press the button to use the
unit without subwoofer. Please note that the unit will therefore reach its limits sooner.
1
2
3
4
5
6
7
ombined socket-type input signal connector. This is a balanced connector just like the
LOOP THRU connector with the following pin assignments
) MIC/LINE :
Button for switching between microphone and line sensitivities.
) FUSE :
Fuse holder. Use only the recommended fuse type and size.
) AC INPUT :
Standard IEC-60320 mains connector.
8
NEVER PRESS THIS BUTTON
WITHOUT FIRST REDUCING THE LEVEL OF THE UNIT TO AVOID EXTREMELY HIGH SPL.
9
10
Only use this equipment with an appropriate mains cord.
avant
avant
15A
215A
&
amplifier
BOOST/FLAT
avant
15A
MIC/LINE
LOOP THRU
INPUT
LIMIT
SIGNAL
ON
CAUTION
D.A.S. AUDIO S.A. (Valencia)
MADE IN SPAIN
T5 A L 250V FUSE
FOR CONTINUED PROTECTION
AGAINST RISK OF FIRE REPLACE
ONLY WITH THE SAME TYPE
230V
2A 50Hz/60Hz
DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE
N1918
RISK OF ELECTRIC SHOCK
DO NOT OPEN
20080011
+6
-oo
0
0
LEVEL
2
1
1
3
4
4
5
5
9
9
10
11
8
7
6
6
4
20
50
100
200
500
1k
2k
5k
10k
20k
Hz
130.0
dBSPL
120.0
110.0
100.0
90.0
80.0
Boost
Flat
