Crosman SASS32PA - Manual

Tactical Soft Air Rifle
6mm Plastic BBs
OWNER'S MANUAL
READ ALL INSTRUCTIONS AND WARNINGS IN THIS
MANUAL BEFORE USING THIS SOFT AIR RIFLE
Distributed by
Crosman Corporation
7629 Routes 5 & 20,
East Bloomfield, NY 14443
www.crosman.com
1-800-7AIRGUN or 1-800-724-7486
SASS32PA-515
SPECIFICATIONS
PERFORMANCE
Many factors affect velocity, including brand of projectile,
type of projectile and barrel condition.
Mechanism/Action Single shot spring pump
Caliber/Ammunition 6mm plastic BBs
Magazine Capacity Up to 240 plastic BBs
Barrel Material Smooth bore aluminum
Weight 4.21 lbs. (1.91 kg)
Overall length Up to 30.25 in. (76.20 cm)
Safety Cross bolt
Velocity Up to 350 fps (106.7 m/s)
REPAIR SERVICE
If your soft air rifle needs repair, we recommend that you call Crosman Corporation Customer Service at 1-800-724-7486
or 585-657-6161 or visit our web site at www.crosman.com. (International customers should contact their distributor.) DO
NOT ATTEMPT TO DISASSEMBLE IT! Your soft air gun requires special tools and fixtures to repair it. Any disassembly
or modification not performed by an Authorized Service Station will void the warranty and could be dangerous.
LIMITED 30-DAY WARRANTY
This product is warranted to the retail consumer for 30 days from date of retail purchase against defects in material and
workmanship and is transferable. You should retain the original sales receipt as record of date of purchase.
WHAT IS COVERED
Replacement parts and labor. Transportation charges to consumer for repaired product.
WHAT IS NOT COVERED
Transportation charges to Crosman for product. Damages caused by abuse or failure to perform normal
maintenance (See Step 8). Any other expense. CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES,
OR INCIDENTAL EXPENSES, INCLUDING DAMAGE TO PROPERTY. SOME STATES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
WARRANTY CLAIMS
USA Customers: Attach your name, address, description of problem, phone number and copy of sales receipt to
product. Package and return to Crosman Corporation, Rts. 5&20, E. Bloomfield, NY 14443.
Canadian Customers: Follow packaging procedures above and send to Crosman Parts & Service Depot, 611 Neal
Drive, Peterborough, Ontario K9J 6X7 Canada.
International Customers: Please return product to your nearest distributor. If you do not know your distributor,
please call 585-657-6161 and ask for our International Department for assistance.
IMPLIED WARRANTIES
ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM DATE OF RETAIL PURCHASE.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
To the extent any provision of this warranty is prohibited by federal, state, or municipal law which cannot be
preempted, it shall not be applicable. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state and country to country.
5. Pumping Your Soft Air Rifle
• Put the soft air gun "ON SAFE" (See Step 2A).
• Holding the forearm firmly, pull it all the way back. Do not twist
the forearm while pumping. Use a straight stroke to prevent
breakage (Fig. 5).
• Return the forearm to the original closed position with a smooth
stroke. Be sure to hold the forearm firmly as you close it.
NOTE: You must follow the procedure for pumping and firing your soft air gun each
time you shoot.
6. Adjusting the Hop Up
Your soft air gun is manufactured with a hop-up system. The purpose of this system is to change
the spin on the BB as it leaves the muzzle allowing you to adapt your shot for different distances.
• Make sure the soft air gun is "ON SAFE" (see section 2A)
and the magazine is removed.
• Point the soft air gun in a SAFE DIRECTION.
• Locate the hop up adjustment slide on the side of the gun (fig. 6)
Push the slide back for less spin or forward for more spin.
7. Aiming and Firing Safely
7.1 Aiming Safely
• You and others with you should always wear shooting glasses to protect your eyes.
• Always aim your soft air rifle in a SAFE DIRECTION. When you are sure of your target and
backstop, and the area around the target is clear, pump the soft air rifle (See Step 4), take
"OFF SAFE" (See Step 2.2) and squeeze the trigger to fire.
• Do not shoot at hard surfaces or at the surface of water. The plastic BBs may bounce off or
ricochet and hit someone or something you had not intended to hit. If the plastic BBs should
happen to hit a hard surface, DO NOT reuse those plastic BBs because they could cause
possible damage to your soft air rifle.
• Always choose your target carefully. It is best to shoot at targets, which are attached to a
safe backstop. Your backstop should be checked for wear before and after each use.
Replace your backstop if the surface is worn or damaged, or if a ricochet occurs.
• Your soft air rifle is designed for target shooting and is suited for both indoor and outdoor
use. Always remember to place your target carefully. THINK about what you will hit if you
miss the target, or if the plastic BB richochets.
7.2 Firing Safely
• Make sure the soft air rifle is "ON SAFE" (See Step 2.1).
• Point the soft air rifle in a SAFE DIRECTION.
• Follow section 5 on pumping the soft air gun.
• After reading section 7 on aiming and firing safely, take the soft air gun "OFF SAFE" and pull
the trigger.
• Repeat these steps until you are no longer firing plastic BBs.
• Put the soft air gun back "ON SAFE".
• Remove the magazine.
8. Maintaining Your Soft Air Rifle
• Tampering with the soft air rifle or attempts to change the soft air rifle in any way may make
it unsafe to use, cause injury particularly to the eye, and will void the warranty.
• If you drop your soft air rifle, check to see that it works properly before you use it again. If anything
seems changed, like a shorter or weaker trigger pull, this may mean worn out or broken parts.
Call Customer Service at Crosman for assistance before using your soft air rifle again.
9. Reviewing Safety
• Do not ever point the soft air rifle at any person. Do not ever point the soft air rifle at
anything you do not intend to shoot.
• Always treat the soft air rifle as though it is loaded and with the same respect you
would a firearm.
• Always aim in a SAFE DIRECTION. Always keep the muzzle of the soft air rifle pointed in a
SAFE DIRECTION.
• Always keep the soft air rifle "ON SAFE" until you are ready to shoot in a SAFE DIRECTION.
• Always check to see if the soft air rifle is "ON SAFE" and unloaded when getting it from
another person or from storage.
• Always keep your finger off the trigger and out of the trigger guard until ready to shoot.
• If your reading or prescription glasses are not safety glasses make sure you wear shooting
glasses over your regular glasses.
• Use 6 mm plastic BBs only.
• Do not shoot at hard surfaces or at the surface of water. The plastic BBs may bounce off or
ricochet and hit someone or something you had not intended to hit. If the plastic BBs should
happen to hit a hard surface, DO NOT reuse those plastic BBs because they could cause
possible damage to your soft air rifle.
• Replace the backstop if it becomes worn. Place the backstop in a location that will be safe
should the backstop fail.
• Do not attempt to disassemble or tamper with your soft air rifle. Call Customer Service at
Crosman Corporation for repair.
• Do not put the soft air rifle away loaded. Make sure ALL of the plastic BBs are unloaded
from the soft air rifle (See Step 3.2).
• Always store this soft air rifle in a secure location.
YOU AND OTHERS WITH YOU SHOULD ALWAYS WEAR SHOOTING GLASSES TO PROTECT YOUR EYES.
READ ALL INSTRUCTIONS BEFORE USING.
BUYER AND USER HAVE THE DUTY TO OBEY ALL LAWS ABOUT THE USE AND OWNERSHIP OF THIS
SOFT AIR RIFLE.
Please read this owner's manual completely. Remember, to treat this soft air rifle with the same
respect you would a firearm. Always carefully follow the safety instructions found in this owner's
manual and keep this manual in a safe place for future use.
If you have any questions, regarding your new soft air rifle, please contact Crosman Customer
Service at 1-800-724-7486, 585-657-6161 or www.crosman.com.
1. Learning the Parts of Your New Soft Air Rifle
Learning the names of the parts of your new soft air rifle will help you to understand your owner's
manual. Use this manual to increase your enjoyment of this soft air rifle.
2. Operating the Safety
2.1 To Put the soft air gun "ON SAFE:"
• Locate the safety directly behind the trigger.
• Push the safety from the left side all the way in (Fig. 2).
The safety is not "ON SAFE" unless it is pushed all the way
in and the RED ring around the left side of the safety is
NOT showing.
Like all mechanical devices, a soft air gun safety can fail. Even when
the safety is "ON SAFE", you should continue to handle the soft air gun safely. NEVER point the soft air gun
at any person. NEVER point the soft air gun at anything you do not intend to shoot.
2.2. To Take the soft air gun "OFF SAFE":
• Push the safety from the right side all the way in. When you can see the RED ring around the
left side of the safety, the airgun is "OFF SAFE" and can be fired.
3. Loading and Unloading Plastic BBs
3.1 Loading Plastic BBs
• Make sure the soft air rifle is "ON SAFE" (See Step 2.1).
• Point the soft air rifle in a SAFE DIRECTION.
• Release the BB magazine by pushing in on the magazine release tabs on
both sides of the magazine (Fig. 3).
• Slide open the door on top of the magazine.
• Pour up to 240 plastic BBs in to the magazine.
• Close the loading door.
• Insert the loaded magaizne back into the soft air gun.
• Rotate the wind up wheel to draw plastic BBs up into the ready tube (Fig. 3).
• As you use up the BBs you will need to continue to rotate the wind up
wheel in order to keep the ready tube supplied with BBs and the gears at
the proper tension.
NOTE: For optimum performance keep a supply of BBs in th reservior to help load BBs into
the ready tube.
3.2 Unloading the Plastic BBs-
• Make sure the soft air gun is "ON SAFE" and pointed in a SAFE DIRECTION.
• Press the magazine release button to release the magazine.
• With the magazine out of the gun, point the soft air rifle in a SAFE DIRECTION.
• Follow section 5 on pumping the soft air gun.
• After reading section 7 on aiming and firing safely, take the gun"OFF SAFE" and pull the trigger.
• Repeat these steps until you are no longer firing plastic BBs.
• Put the airgun"ON SAFE".
• Do not put the magazine back in the gun. Since some BBs will remain in the magazine,
store the clip seperate from the gun.
4. Adjusting the Stock
The gun is designed with a stock that is adjustable to six different positions.
• Make sure the soft air gun is "ON SAFE" and pointed in a SAFE DIRECTION.
• Push up and release the stock adjustment lever.
• Pull the stock out until it clicks into place.
• Repeat until the stock is in the desired position.
Fig. 1
Not a toy. Adult supervision required. Misuse or careless use may
cause serious injury, particularly to the eye. May be dangerous up
100 yards (91.44 meters).
WARNING:
STEPS FOR SAFE SHOOTING
1. Learning The Parts Of Your New Soft Air Rifle
6. Adjusting the Hop Up
2. Operating the Safety 7. Aiming and Firing Safely
3. Loading And Unloading Plastic BBs 8. Maintaining Your Soft Air Rifle
4. Adjusting the Stock 9. Reviewing Safety
5. Pumping Your Soft Air Rifle
Keep the soft air rifle in the "ON SAFE" position until you are actually
ready to shoot. WARNING:
THIS SOFT AIR RIFLE IS INTENDED FOR USE BY THOSE 16 YEARS OF AGE OR OLDER.
Trigger Safety - See Fig. 2
Muzzle
Magazine
Release
Use 6 mm plastic BBs only in this soft air rifle. Use of any other
ammunition can cause injury to you or damage to the soft air rifle. WARNING:
Magazine
Release
Fig. 3
Never assume that because the soft air gun no longer fires a plastic BB
and/or the magazine is removed, that a plastic BB is not lodged in the
barrel. Always treat the soft air gun as though it is loaded and with the same respect you
would a firearm.
WARNING:
Fig. 5
Never pump your soft airgun more than once. Over-pumping can cause
major damage to your soft air gun. WARNING:
Magazine
Forearm
Stock
Fig. 2
Do not brandish or display this soft air gun in public – it may confuse
people and may be a crime. Police and others may think it is a firearm.
Do not change the coloration and markings to make it look more like a firearm. That is
dangerous and may be a crime.
WARNING:
ON SAFE OFF SAFE
Wind-Up
Wheel
Always hold the forearm firmly when you pump it to prevent possible injury.
WARNING:
Fig. 6
Stock Adjustment
lever
Hop Up Adjuster
