Crosman Pulse R71

Model SAPR71

Soft Air Gun 6mm Plastic BB

OWNER’S MANUAL

Distributed by

Crosman Corporation

7629 Routes 5 & 20

East Bloomfield, NY 14443

www.crosman.com

1-800-7AIRGUN

1-800-724-7486

Made in China

SAPR71-515

WARNING:

This is not a toy. Adult supervision is required. Misuse may cause

serious injury, especially to the eye. Eye protection designed for soft air guns

must be worn by the user and any person in range. May be dangerous up to 100

yds. Read the owner’s manual before using.

WARNING:

Do not brandish or display this soft air gun in public – it may con-

fuse people and may be a crime. Police and others may think it is a firearm. Do

not change the coloration and markings to make it look more like a firearm. That

is dangerous and may be a crime.

READ ALL INSTRUCTIONS AND WARNINGS IN THIS MANUAL BEFORE USING THIS SOFT AIR GUN.

BUYER AND USER HAVE THE DUTY TO OBEY ALL LAWS ABOUT THE USE AND OWNERSHIP OF THIS

SOFT AIR GUN.

Recommend 18 years or older to purchase. Intended for use by those 16 or older.

Please read this owner’s manual completely. Remember to treat this soft air gun with the same respect you would

a firearm. Always carefully follow the safety instructions found in this owner’s manual and keep this manual in a

safe place for future use.

If you have any questions regarding your new soft air gun, please contact Crosman Customer Service at: 1-800-

724-7486, 585-657-6161 or www.crosman.com.

1. Learning the Parts of Your New Soft Air Gun

Learning the names of the parts of your new soft air gun will help you to understand your owner’s manual. Use

this manual to increase your enjoyment of this soft air gun.

A. Muzzle

B. Compensator*

C. Loading Chamber

D. Removable stock

E. Trigger Guard

F. Trigger

G. Battery Release Lever

H. Battey

I. Firing Mode Selector (see Fig. 2)

J. Safety (see Fig. 2)

*Your soft air gun has been designed to

be used with or without the enclosed

compensator. To attach the compensa-

tor, screw on the barrel tip until tight. Do

not over tighten as it may damage the

compensator or barrel.

2. Operating the Safety

A. To put the soft air gun “ON SAFE”

• Locate the safety on the left hand side of the soft air gun.

• Push the safety all the way up until you hear/feel it click into place and the safety is lined up with “S” for “ON

SAFE” (Fig 2A). The safety is not “ON SAFE” unless it is pushed all the way up to the “S”.

WARNING:

Keep the soft air gun in the “ON SAFE” position until you are actu-

ally ready to shoot. Then turn the safety to the “OFF SAFE” position.

Like all mechanical devices, a soft air gun safety can fail. Even when

the safety is “ON SAFE”, you should continue to handle the soft air gun

safely. NEVER point the soft air gun at any person. NEVER point the

soft air gun at anything you do not intend to shoot.

B. To Take the Soft Air Gun “OFF SAFE”

NOTE: This soft air gun fires in either full-auto or semi-auto mode. Full-

auto means it will continue to fire plastic BBs as long as you hold the

trigger. Semi-auto means you will have to pull the trigger each time you

want to fire a shot.

• Locate the safety on either side of the receiver. (Fig. 2)

• Push the lever to the semi-auto fire or full auto fire position.

• The soft air gun is “OFF SAFE” and ready to fire when pointing to

either of these locations.

3. Using the Battery

A. Charging the Battery

NOTE: Charge the battery a MINIMUM of 2 hours and a MAXIMUM of 3

hours prior to initial use. This soft air gun will not operate properly without

a fully charged battery. DO NOT OVERCHARGE THE BATTERY. UNPLUG

THE BATTERY CHARGER WHEN NOT IN USE.

Continuous battery consumption will allow the soft air gun to shoot for

10-12 minutes. To prolong battery life and maintain the best shooting per-

formance do not shoot over 5 minutes continuously in the Full Auto Mode.

For optimum performance completely use up the battery before recharging.

• Remove the battery from the soft air gun (see section 3C).

• Plug the charger into the bottom of the battery.

• Plug the charger into a standard 110v outlet.

B. Loading the Battery

• Make sure the soft air gun is “ON SAFE” (section 2A) and

is UNLOADED.

• Point the soft air gun in a SAFE DIRECTION.

• Disconnect the battery from the charger.

• Insert the battery into the gun so that the metal connectors (positive end)

are on top and lock battery in place (fig. 3).

C. Removing the Battery

• Make sure the soft air gun is “ON SAFE” (section 2A) and is UNLOADED.

• Point the soft air gun in a SAFE DIRECTION.

• While holding the soft air gun in a horizontal position press the battery

release lever forward with one hand, and pull the battery out with the

other hand (fig. 4).

4. Loading and Unloading Plastic BBs

A. Loading

WARNING:

Use 6 mm plastic BBs only in this soft air gun. Use of any other

ammunition can cause injury to you or damage to the soft air gun.

• Make sure the soft air gun is “ON SAFE” (section 2A) and pointed in a SAFE DIRECTION.

• To install the loading chamber

• Loosen the mounting screws on the loading chamber

• With the small end toward the back of the gun, place the loading chamber on the top rail, being sure to line

up the hole on the bottom of the loading chamber with the hole in the rail (fig. 5). Small arrows on the mount

will also help align the loading chamber.

• Tighten the mounting screws.

• Once the loading chamber has been installed slide open the loading

chamber door on top.

• Fill the loading chamber with up to 500 BBs and slide the door closed.

B. Unloading Plastic BBs

• Make sure the soft air gun is “ON SAFE” (section 2A) and pointed in

a SAFE DIRECTION.

• Loosen the mounting screws and remove the loading chamber, being

careful not to spill out the BBs.

• To empty the chamber slide open the door on top and pour the BBs out

into a container or your hand.

• Point the soft air gun in a SAFE DIRECTION, take “OFF SAFE” and fire

the gun in a safe direction until no more BBs fire.

• Put the soft air gun back “ON SAFE”.

WARNING:

Never assume that because the soft air gun no longer fires a BB

and/or the loading chamber is removed, that a BB is not lodged in the barrel.

Always treat the soft air gun as though it is loaded and with the same respect you

would a firearm.

5. Installing and Removing the Stock

• To install, line stock up with grooves at the back of the rifle. (Fig. 6) With the stock in this position push the

stock down until it locks into place.

• To remove the stock, pull the stock release button toward the back of the stock. Push the stock upward until

it has cleared the rail.

6. Aiming and Firing Safely

• You and others with you should always wear eye protection

designed for soft air to protect your eyes.

• Always point your soft air gun in a SAFE DIRECTION.

• Do not shoot at hard surfaces or at the surface of water.

The plastic BBs may bounce off or ricochet and hit someone

or something you had not intended to hit.

• DO NOT re-use plastic BBs because they could possibly

cause damage to your soft air gun.

• Your soft air gun is designed for target shooting and is suited

for both indoor and outdoor use. Always remember to place

your target carefully. THINK about what you will hit if you

miss the target.

• When you are sure of your target and backstop, and the area

around the target is clear, charge and load soft air gun following sections 3 and 4. Take the soft air gun

“OFF SAFE” (section 2A) aim and pull the trigger to fire.

• NOTE: This soft air gun fires in either full-auto or semi-auto mode. Full-auto means it will continue to fire

plastic BBs as long as you hold the trigger. Semi-auto means you will have to pull the trigger each time you

want to fire a shot.

7. Maintaining Your Soft Air Gun

• DO NOT MODIFY OR ALTER YOUR SOFT AIR GUN. Tampering with the soft air gun or attempts to change

the soft air gun in any way may make it unsafe to use, may cause serious injury or death and will void

the warranty.

• If you drop your soft air gun, visually check to see that it works properly before you use it again. If anything

seems changed, like a shorter or weaker trigger pull, this may mean parts are worn out or broken. Call

Customer Service at Crosman for assistance before using your soft air gun again.

8. Reviewing Safety

• Do not ever point the soft air gun at any person. Do not ever point the soft air gun at anything you do not

intend to shoot.

• Always treat the soft air gun as though it is loaded and with the same respect you would a firearm.

• Always aim in a SAFE DIRECTION. Always keep the muzzle of the soft air gun pointed in a

SAFE DIRECTION.

• Always keep the soft air gun “ON SAFE” until you are ready to shoot in a SAFE DIRECTION.

• Always check to see if the soft air gun is “ON SAFE” and unloaded when getting it from another person or

from storage.

• Always keep your finger off the trigger and out of the trigger guard until ready to shoot.

• You and others with you should always wear eye protection to protect your eyes.

• If your reading or prescription glasses are not safety glasses make sure you wear shooting glasses or soft air

goggles over your regular glasses.

• Use 6 mm plastic BBs only.

• Do not shoot at hard surfaces or at the surface of water. The plastic BBs may bounce off or ricochet and hit

someone or something you had not intended to hit.

• Replace the backstop if it becomes worn. Place the backstop in a location that will be safe should the

backstop fail.

• Do not attempt to disassemble or tamper with your soft airgun.

• DO NOT MODIFY OR ALTER YOUR SOFT AIRGUN. Attempts to modify the soft air gun in any way may

make your soft air gun unsafe to use, cause serious injury or death and will void the warranty.

• Using unauthorized repair centers or modifying the function of your soft air gun in any way may be unsafe

and will void your warranty.

• Do not put the soft air gun away loaded. Make sure ALL of the plastic BBs are unloaded from the

soft air gun.

• Always store this soft air gun in a secure location.

SPECIFICATIONS

Mechanism/Action

Electronic

Caliber/Ammunition

6mm Plastic BBs

Magazine

Up to 500 6 mm BBs

Safety

Lever

Velocity

Up to 200 fps

Battery

8.4V 300mA

PERFORMANCE: Many factors can affect velocity, including brand of projectile, type of projectile and barrel

condition.

CUSTOMER SERVICE

If your soft air gun is not functioning, we recommend that you call Crosman Corporation Customer service at

1-800-724-7486 or 585-657-6161. (International customers should contact their distributor.) DO NOT ATTEMPT

TO DISASSEMBLE IT! If you take it apart you probably will not be able to reassemble it correctly. Crosman as-

sumes no warranty responsibility under such circumstances.

LIMITED 30 DAY WARRANTY

This product is warranted to the retail consumer for 30 days from date of retail purchase against defects in mate-

rial and workmanship and is transferable.

WHAT IS COVERED

Replacement parts and labor. Transportation charges to consumer for repaired product.

WHAT IS NOT COVERED

Transportation charges to Crosman for product. Damages caused by abuse, modification or failure to perform

normal maintenance. Any other expense. CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, OR INCI-

DENTAL EXPENSES, INCLUDING DAMAGE TO PROPERTY. SOME STATES DO NOT ALLOW THE EXCLUSION

OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLU-

SION MAY NOT APPLY TO YOU.

WARRANTY CLAIMS

USA Customers: Attach your name, address, description of problem, phone number and copy of sales receipt to

product. Package and return to Crosman Corporation, Routes 5 & 20, East Bloomfield, NY 14443.

International Customers: Please return product to your nearest distributor. If you do not know your distributor,

please call 585-657-6161 and ask for our International Department for assistance.

IMPLIED WARRANTIES

ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO 30 DAYS FROM DATE OF RETAIL PURCHASE.

SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE

ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

To the extent any provision of this warranty is prohibited by federal, state, or municipal law which cannot be

preempted, it shall not be applicable. This warranty gives you specific legal rights, and you may also have other

rights which vary from state to state.
