Displaying the Source Address List 5-3
Source Addressing
Figure 5-2. The Source Address List Window
The Source Address List window displays addresses of all devices that have
transmitted packets through the SEHI within a time period less than the SAT’s
defined ageing time (addresses that have not transmitted a packet during one
complete cycle of the ageing timer will be purged). The Ageing Time is user-
configurable; see
Setting the Ageing Time , page 5-4 . The list window can display
about ten addresses at once; use the scroll bar to the right of the list window to
view additional addresses, if necessary.
Since the SAT is constantly changing as old entries are aged out and new ones
learned from the network, you should occasionally update the displayed list by
clicking mouse button 1 on
. Once displayed, the list is static and will
not reflect recent changes. Also static is the displayed number of Active Users;
this field will also update when you click on
.
NOTE
Some entries in the Source Address List window may list port numbers 25 or 26; port 25
represents EPIM 1, and port 26 represents EPIM 2.
