3.8L & 4.0L Automatic WITHOUT Engine Oil Cooler

Engine/Transmission

GCWR (Gross Com-

bined Wt. Rating)

Frontal Area

Max. GTW (Gross

Trailer Wt.)

Max. Tongue Wt.

3.8L & 4.0L Auto-
matic WITHOUT
Engine Oil Cooler

7,700 lbs (3 492 kg)

40 SQ. FT.

Up to 2 persons &

Luggage 2,600 lbs

(1 179 kg)

260 lbs (117 kg)

7,700 lbs (3 492 kg)

40 SQ. FT.

3 to 4 persons &

Luggage 2,100 lbs

(952 kg)

210 lbs (95 kg)

N/A

5 to 6 persons &

Luggage NOT Rec-

ommended

N/A

Refer to local laws for maximum trailer towing speeds.

NOTE:

Your vehicle must be equipped with a trailer

tow package (trailer hitch and engine oil cooler) in order
to tow a gross trailer weight of 3,500 lbs (1 600 kg).
