Warning
• Do not set “Audio Out Select” to “Bitstream” from the on-screen displays unless you are connecting (via the
BITSTREAM/PCM AUDIO OUT jack) an AV decoder that has the Dolby Digital, Digital Theater Systems (DTS) or MPEG2
decoding function. High volume sound may damage your hearing as well as the speakers.
• When playing DTS-encoded discs (DVD video discs and audio CDs), excessive noise may be output from the analog
stereo jacks. To avoid possible damage to the audio system, you should take proper precautions when the 2CH AUDIO
OUT jacks of the DVD video player are connected to an amplification system. To enjoy DTS Digital Surround™ playback,
an external 5.1 channel DTS Digital Surround‘d“ decoder system must be connected to the BITSTREAM/PCM AUDIO OUT
jack of the DVD video player.
Connecting to an amplifier equipped with a DTS decoder
Digital Theater Systems (DTS)
DTS is a high quality surround technology used in theaters and now available for home use,
on DVD video discs or audio CDs.
If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS
encoded sound tracks on DVD video discs or audio CDs.
“DTS” and "DTS Digital Surround” are
trademarks of Digital Theater Systems,
Inc.
^ Amplifier equipped with
a DTS decoder
To OPTICAL Al
type digital
audio input
To COAXIAL
type digital
audio input
9 m
• « é ® i
® <ê jij
Use DVD video discs or audio
CDs encoded via the DTS
recording system.
Make the following setting.
o
o
3
3
(D
O
5'
3
0>
-C=^
<=>
Connect either.
75 n coaxial cable
Optical digital cable
»
Setting Select: Page
“Audio Out Select” “Bitstream”
HD
[3?)
Recording system DTS (33>
Connecting to an amplifier equipped with an MPEG2 audio decoder
MPEG2 sound
You can enjoy motion picture and live concert DVD video discs with dynamic realistic sound
by connecting an amplifier equipped with an MPEG2 audio decoder or MPEG2 audio
processor.
□ oca
Q ^
Amplifier equipped with an
MPEG2 audio decoder
To CPTICAL A|
type digital U
audio input I To CCAXIAL
I type digital
audio input
* ®“1
I ^
® ® Q :
' @
Use DVD video discs encoded via
the MPEG2 recording system.
Make the following setting.
■Oi
Connect either./
75 n coaxial cable_____ j
Optical digital cable
Setting Select: Page
“Audio Out Select” “Bitstream”
(H>
[39>
Recording system MPEG HD
Connecting to an amplifier equipped with a digital audio input
2 channel digital stereo
You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifier
equipped with a digital audio input and speaker system (right and left front speakers).
Amplifier equipped with
a digital audio input
To OPTICAL j3
type digital
audio input
To COAXIAL
type digital
audio input
-O-
<73-
Н
® ■ : ' й ® ®
# © j ' @ @
#1 '
^il* *f • Make the following setting.
Connect either, A a
75 il coaxial cable y y
Optical digital cabl^^^^J
Setting Select: Page
“Audio Out Select” “PCM”
dD
ID
Notes
• DO NOT connect the BITSTREAM/PCM AUDIO OUT jack of the DVD video player to the AC-3 RF input of a Dolby Digital
Receiver. This input on your A/V Receiver is reserved for Laserdisc use only and is incompatible with the BITSTREAM/PCM
AUDIO OUT jack of the DVD video player.
• Connect the BITSTREAM/PCM AUDIO OUT jack of the DVD video player to the “OPTICAL” or “COAXIAL” input of a Receiver
or Processor.
• Refer to the owner's manual of the connected equipment as well.
• When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of the equipment
from the wall outlet before making any connections,
• The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the DVD video player’s power cord. If you leave the amplifier power
on, the speakers may be damaged.
