4 start up / power off the board, Tart, Ower – Compaq SmartModule Express SMX945 User Manual
Page 18: Ff the, Oard
DIGITAL-LOGIC AG
SMX945 Condensed Manual V1.0A
18
4.
S
TART
U
P
/
P
OWER
O
FF THE
B
OARD
With the PWRBTN# signal, the system can be started. Activating this signal a second time will shut the
system down.
How to Activate PWRBTN#
The PWRBTN# signal must be connected to a ground to be activated.
Minimum activation time is 3 seconds for the controller to start/stop the system.
A few seconds after powering up the board, the screen should display the BIOS initial messages/pictures.
