DIGITAL-LOGIC AG SMX945 Condensed Manual V1.0A
13
Intel 945GME Graphics PEG
PEG Controller
Alternative to the internal graphic controller
Multiplexed with the SDVO signals
Specification
Support PEG
Mode 16 lanes
Voltage 1.5Volt
Signals Differential 2.5Gbit/sec
Intel 82801DBM (ICH7DH) Specification
PCI-Bus Supports PCI 2.2 with 6 resources
EIDE-Bus 1x Ultra P-ATA 100
SATA-Bus 2 channels 150MByte/sec
USB V2.0 8 channels USB
APIC INTEL I/O APIC
SMB V2.0 SMBus controller
FWH Firm Ware Hub for BIOS devices
LPC Serialized BUS (no ISA) used for external SuperIO
(COM1/2, MS, KB, FD and LPT)
Sound AC97 2.3 HDA Interface with 192kHz sampling rate and 8 channels
IRQ Controller 8259 compatible
Timers 8254 compatible
Power Management Integrated
Reset & Power Management Specification
Controller PIC 16C870
Power Modes S5, S4, S3, S1
ACPI V3.0
BUS Specification
PCI PCI 2.2 33MHz 32bit
LPC 8bit 33MHz
PCIexpress 6x 1 lane, PEG
Power Supply Specification
DC Input 5.0V up to maximum 18V, max. 200mV ripple
up to 30 Watts peak for VCCCore, 2.5V and 1.25V generation
Inrush current 5.0V up to 10Amp for 100µs
18.0V up to 30Amp for 20µs
5.0Volt 0.1Amp (VCC5ALW)
Onboard Voltages VCC-Core, 1.05V, 1.2V, 1.25V, 1.3V, 1.5V, 1.8V, 2.5V, 3.3V
Power Consumption 800MHz: approx. 6Watts @ 512MByte DDR2-RAM, Desktop load
1.6GHz: approx. 24Watts @ 512MByte DDR2-RAM, 100% workload
use inductors in series to reduce the maximum inrush current!
