DIGITAL-LOGIC AG SMX945 Condensed Manual V1.0A
12
2.4. Specifications
CPU Specification
CoreDuo / Celeron M Intel Core Duo L2400 LV 2x 1.66GHz with 2MB L2-cache
Intel Core 2 Duo L7400 LV 2x 1.66GHz with 4MB L2-cache
Intel Celeron M423
ULV 1x 1.06GHz with 1MB L2-cache
Intel Celeron M440 1x 1.86GHz with 1MB L2-cache
Clock 1GHz up to 1.86GHz
1
st
Level Cache 2x 32kByte
2
nd
Level Cache 1, 2, 4 MByte (on die)
Technology 65nm
VCCCore @ 1.6GHz 1.308V
VCCCore @ 0.6GHz 0.844V
VCCCore @ deep sleep 0.748V
CPU-Bus AGTL+
AGTL+ Termination Integrated
FSB 533/666MHz quad-pumped synchron bus
Mathematics Coprocessor
Available on the PENTIUM CPU
Intel 945GME Graphics Memory Controller Hub
Memory Controller
Specification
Supports PC1600 / PC2100 / PC2700
Socket DDR2 SODIMM 200pin
Technologies DDR2-667
Capacity 256MByte up to 2GByte (3GByte with SMX945B)
Voltage 2.5V
Termination 1.25V
Width 64bit
ECC-Support No
Intel 945GME Graphics Memory Controller Hub
Graphic Controller
Alternative to the PEG Interface
Specification
Max. Video memory 224MByte with Intel GMA950
Graphic Core Frequency 400MHz
3D Graphic Engine 3D-setup and rendering engine
Zone rendering
Texture engine
Direct-X Compatibility Direct-X9
Analog CRT 400MHz RAMDAC with 24bit
Resolution up to 2048 x 1536 @ 70Hz (QXGA)
Hardware cursor support
I2C and DDC channels
Dual independent display
SDVO Port 2 channels (multiplexed with the PEG signals)
2x 200 Mpixel/sec
Support for up to 2x DVI, 1x TV and 2x LVDS
Dotclock = 165MHz
Compliant with DVI Spec.1.5
Flat Panel Interface 2 channel LVDS interface
1x 18, 2x 18, 1x24, 2x24bpp TFT
Dotclock = up to 2x 112 MHz
Resolutions 640 x 480 up to 1600 x 1200 (UXGA)
Automatic panel detection via VESA EDID 1.3
TV Out Disabled.
A Macrovision license is required.
