Kandy Programmer (HP911A)
Net«:
SameTl & r jtictlons are limited wild usmg ttie HPiii lA,
Tile HP911A is a hard-held graphic programmer. Its
portability makes it ideal for maintenance use at remote
locations. The HP911A has all the features of a full size
programming terminaJ. (2 m cable for T1 is included)
• Ladder logic programming of T-Series programmable
controllers T1/T1S, T2/T2E/T2N and T3.
• Suilt-in EEPROM allows program copy between
T-Series controllers.
• Two display modes,
- Normal: S lines and 12 columns
- Zoom: Full device description
• Data monitor for I/O and internal registers.
• On-line programming & EEPROM write. (T1S)
• On-line data set & I/O force.
• Backlit LCD display for better operation In dim light.
Program Storage Module (RM102)
The RM102 is an external memory device, which can
store a T1/T1S program. By using the RM102, program
transfer from a master T1/T1S can be easily done without
the need for a computer or hand held programmer. Two-
button operation makes program loading/saving
accessible to anyone. However, if a password is used in
the T1/riS, the password in the RM102 must match
before a program load is executed.
Multi-drop Adapter (CU111)
The GU111 is an RS-232C/RS-485 converter dedicated
to then Series, By using theCUm, up to 32 T1/T1Ss
can be connected to a master computw or higher level
controller via an RS-485 link, The master computer can
run a SCADA, MM! or DDE Server program. The T-PDS
programming software can also be used through the RS-
485 link to program or monitor each individual T1/T1S,
(T1 version 1.20 or later is required for connecting the
T-PDS programming software)
