11. SPECIFICATIONS
Power
AC 24V ± 10% 60 Hz 5.0W (MAX)
Image sensor
1/3 inch CCO image area sensor
Image pickup area
4.9 mm (0.193inch) horizontal x 3.7mm (0.146inch) vertical
(1/3inchtype)
Effective picture element
512 horizontal
X
492 vertical
Scanning system
2;1 interlace
Scanning frequency
15.75kHz horizontal 60Hz vertical
Synchronization
Line-Lock, Internal
Resolution
Horizontal 330TV lines or more
Vertical 350TV lines or more
Minimum iliuminance of subject
0.4Lux (F1.2, More than 10% of image output
r =
0.45 )
S/N
46 dB or more
Video output
VBS 1.0 V p-p NTSC system
Output impedance
75 n unbalanced
White balance
Automatic (3000‘ K to 6000 ‘K)
Lens mount
mount both C and CS
Ambient temperature
-10'Cto+50’C(14'Fto122T)
Ambient humidity
30% to 90%
Weight
700 g(MAX)
External dimensions
2.76(W)
X
2.36(H)
X
4.90(D) inches (70x60x124.38mm)
Automatic electronic shutter
ON (1/60S to 1/80000S) / OFF (1/60s)
■ Design and specifications are subject to change without notice.
