SKU 98525 For technical questions, please call 1-800-444-3353. Page 13
partS liSt
part description Qty
1 Driven Gear Shaft 1
2 Needle Roller 2
3 Bevel Gear 2
4 Ball Bearing 1
5 Blade Holder Flange 1
6 Blade Bolt Flange 1
7 Blade Bolt 1
8 Bevel Gear Casing 1
9 Ball Bearing 1
10 External Stop Ring 1
11 Case Cover 1
12 Guide Plate 1
13 Spring Washer 1
14 Guide Adjustment Bolt 1
15 Main Shaft 1
16 Needle Roller 6
17 Ball Bearing 2
18 Spacer Collar 1
19 Idle Gear 6
20 Internal Gear 1 1
21 Bearing Support 1
22 Drive Shaft 1
23 Ball Bearing 1
24 Internal Gear 2 1
25 Internal Stop Ring 1
26 Distance Nut 1
27 Throttle Handle 1
28 Air Inlet Bushing 1
partS liSt
part description Qty
29 Throttle Valve 1
30 Valve 1
31 O-ring 1
32 Throttle Spring 1
33 Throttle Valve Plug 1
34 O-ring 1
35 Throttle Lever Assembly 1
36 Spring Pin 1
37 Rotor 1
38 Rear End Plate 1
39 Spring Pin 1
40 Ball Bearing 1
41 Rotor Blade 4
42 Cylinder 1
43 Front End Plate 1
44 Bearing Cap 1
45 Washer 1
46 Saw Blade 1
47 4mm Hex Wrench 2
48 5mm Hex Wrench 1
49 Ball Bearing 1
51 Washer 1
K01 Throttle Housing Kit 1 set
K02 Valve Kit 1 set
K03 Drive Shaft Kit 1 set
K04 Bevel Gear Kit 1 set
K05 Main Shaft Kit 1 set
pleaSe read tHe FOllOwing CareFullY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS qUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
qUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR ExPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
record product’s Serial number Here:
note: If product has no serial number, record month and year of purchase instead.
note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
