5-3-5. DYRANGE (Dynamic - Range Boost)
Move the cursor to the position in Fig. Using the
SELECT switches, SELECT the OFF, BOOST.
It is changed the video output from 115 IRE to
155 IRE.
A. OFF (Standard position, max 115 IRE)
B. Boost (High dynamic range position, Max 155
IRE)
5-3-6. EXIT
Move the cursor to the position in Fig. Press the
SELECT switch when save all settings and exit.
CD
5-3-8. DEFAULT
Move cursor to the position in Fig. Press the
SELECT switch to recall the factory settings.
Default position is below :
SHUTTER
AGC
SYNC
BLC
DYRANGE
AUTO / IRIS
ON
LL
OFF
OFF
SHUTTER AUTO
AGC
ON
SYNC LL
BLC
OFF
DYRANGE Cl
EXIT CANCEL DEFAULT
SHUTTER AUTO
AGC
ON
SYNC LL
BLC
OFF
DYRANGE OFF
[EEiCANCEL DEFAULT
V_____________________
J
5-3-7. CANCEL
Move the cursor to the position in Fig. Press the
SELECT switch, exit menu immediately and don't
save.
SHUTTER AUTO
AGC
ON
SYNC LL
BLC
OFF
DYRANGE OFF
EXIT[
¡DEFAULT
SHUTTER AUTO
AGC
ON
SYNC LL
BLC
OFF
DYRANGE OFF
EXIT CANCEliiTaTg
