ACCESSORY AND INSTALL MANNER
ACCESSORY
No. Part namo External view
Number
of unit»
No, Part rtatne External view
Number
of unit!
Power connec­
tion cord
1 ® Bracket 2
@ Speaker cord
1 ®
Flat head screw
(M4x6)
0Bim> 4
(D Panel frame
1 @
Washer assemblies
screw (M4x8)
5
® Side bracket 2 ®
Tapping screw
{<^4x16)
4
■ [IMSTALL MANNER
1. Before installation and wiring, remove the (-) terminal of the battery to prevent shortcir-
cuiting.
2. Connect the input and output cords of the system,
3. Connect the ground to the metal chassis of the car.
4. Connect the back-up power supply lead (yellow).
5. Install the set and after confirming the installation and wirings are correct, connect the
(-} terminal of the battery.
8
(EnJ
If a fuse is blown, first check that the associated wires are
not short-circuited, then replace the fuse with a new one
having the same capacity.
