Crestron C2N-HBLOCK Multi-Type Network Distribution Block
Multi-Type Network Distribution
Block: C2N-HBLOCK
Introduction
The C2N-HBLOCK is a Crestron

control network (Cresnet

) multiple
connector type, network distribution block that provides wiring for up to
15 devices and/or peripherals. The C2N-HBLOCK provides 24 volts
direct current (VDC), Cresnet Y and Z data signals, and ground through
three different types of Cresnet connectors. Using any one of the
connectors as an input source, the remaining connectors may be used as
outputs to other equipment. The C2N-HBLOCK contains light-emitting
diode (LED) indicators that monitor the input power and input data
signals.
Functional Summary
• Provides wiring for up to 15 devices and/or peripherals
• Three different types of Cresnet connectors, all of which are in
parallel
- Eight 3.5mm 4-pin screw terminal connectors (mini Cresnet)
- Five 5mm 4-pin screw terminal connectors (standard Cresnet)
- Three 6-pin RJ11 modular connectors
• Two LEDs enable user to diagnose wiring problems
Operations & Installation Guide – DOC. 8157A Multi-Type Network Distribution Block • 1
