(NOT TO SCALE)
SECT.
IV
PAGE
14
0402
Litho in U.S.A.
GAS ELECTRIC COLD WATER CLEARANCE DRAINAGE
1 1 ⁄
4
˝ IPS line size, 3 ⁄
4
˝ (13mm) connection 120V-1Phase, 60 Hz. 35 psi minimum RIGHT = 3˝ operating, 1 1 ⁄
2
˝ dia.
NATURAL PROPANE BTU 2 Blowers & Controls 60 psi maximum 12˝ if adjoining wall or Do not connect other
Piping 3 ⁄
4
˝ N.P.T. Piping 3 ⁄
4
˝ N.P.T. 72,000 each 150 watts each LEFT = 3˝ units to this drain
Supply pressure Supply pressure Generator, One (E) 1/4" dia. REAR = 3˝
4.50˝ W.C. Min. 11.00˝ W.C. Min. 144,000 total NPT for Generator Allow 6˝ space min. Drain must be vented
14.00˝ W.C. Max. 14.00˝ W.C. Max. from rear and sides
One (D) 1/4" dia when located near Do not use PVC pipe
Manufacturer must be notified if unit will NPT for Condenser combustible walls
be used above 2,000 feet
C D
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are UL/NSF#4 and CSA (AGA, CGA).
Each Compartment has
capacity for:
• Five, 12˝ x 20˝ x 2 1 ⁄
2
˝ deep
Cafeteria Pans.
WATER QUALITY
REQUIREMENTS
The quality of water varies
greatly from region to region.
Steam equipment generators
must be drained daily and
chemically descaled periodically
to ensure proper operation. To
minimize service problems
caused by the accumulation of
minerals and chemicals in water
review the following quality
guidelines with a local water
treatment specialist. Inlet water
that is beyond these specified
guidelines should be treated to
achieve these acceptable limits.
Total Dissolved Solids less than
60 ppm, Alkalinity less than 20
ppm, Silica less than 13 ppm,
pH factor greater than 7.5,
Chlorine less than 30 ppm.
Right - 3”, Left - 3”,
Rear -3”
(12” on control side if adjoining
wall or equipment is over 30”
high for service access)
Contact factory
for variances to
clearances.
A B C DE
