Cleveland Range SteamCraft 24-CDP-10 User Manual
Cleveland, Ultra 10 d, Steamcraft

Cleveland
™
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Fax: 1-216-481-3782
Web Site: www.ClevelandRange.com
Email: [email protected]
STEAMCRAFT
®
GENERATOR STYLE
HIGH SPEED CONVECTION STEAMERS
MODEL:
24-CDP-10
Cleveland Standard Features
■
Cooking Capacity for up to ten 12˝ x 20˝ x 2
1
⁄
2
˝ deep
Cafeteria Pans.
■
Durable 14 Gauge Stainless Steel Construction:
For compartment door, cavity and front.
■
One 60 Minute Electro-Mechanical Timer and Switch
for manual operation. Audible signal for cooking time
completion.
■
Separate Switch for Power “on/off.”
■
Exclusive Steam Cooking Distribution System: Exclusive
Brass Steam Jets produce a high velocity convection steam
without fans. Coved Corner design in cooking compartment
distributes heat evenly, and is easy to keep clean. Creased
top & bottom enhance drainage. Cold Water Condenser for
each compartment maintains a dry steam. Fully insulated
cooking compartment for thermal efficiency. Removable
Stainless Steel Slide Racks.
■
Exclusive “Cool to the Touch” Compartment Door
Design: Free floating inner door with reversible door gasket
provides an air tight seal. Stainless Steel Slam/Latch Door
Latch mechanism for reliability.
■
Condensate Drip Trough: Provided under lower
compartment door to collect condensate.
■
Left Hand Door Hinging: Compartment Doors hinged left,
control on the right.
■
Moisture Separator for incoming steam.
■
Pressure reducing Valve or 20-50 psi steam supply
pressure, based on a
3
⁄
4
˝ line size.
■
Single Cold water Connection.
■
NSF Certified 6˝ Stainless Steel Legs with adjustable
flanged feet for a one inch level adjustment.
■
Standard voltage for controls: 115 volts, 60 Hz. single
phase.
❏ Clean non-toxic, uncontaminated steam is required for all
“Direct Steam” steamers.
Options & Accessories
❐ Second Pressure Reducing Valve for 50-120 psi steam
pressure. (PRV)
Shall be CLEVELAND,
SteamCraft
Ultra 10
, two compartments,
Direct Steam Floor Model Steamer, Model 24-CDP-10, single, large
capacity Pressureless Convection Steamer. Choice of Compartment
Controls, Manual By Pass Operation Mode, Compensating
Thermostat, Exclusive Cold Water Condenser design, Type 430
Stainless Steel exterior and cooking compartments.
❐ Right Hand Door Hinging, Controls on the Right (DHR)
❐ Electronic Timer with Compensating Load Feature (ETC)
❐ ON/OFF Steam Switch only for compartment controls (MC)
❐ 10˝ Stainless Steel Legs (LF10)
❐ Compartment Door Steam Shut Off Switch (SCS)
❐ Cafeteria Pans in depths of 1˝, 2
1
⁄
2
˝, 4˝
and 6˝
❐ Water Filters
❐ Correctional Packages
Short Form Specifications
✔
SteamCraft
®
Ultra 10 D
TWO COMPARTMENT FLOOR MODEL DESIGN
PRESSURELESS CONVECTION STEAMER
DIRECT STEAM, 24˝ WIDE DESIGN
SECT.
IV
PAGE
21
0707
