Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Fax: 1-216-481-3782
Web Site: www.ClevelandRange.com
Email: [email protected]
STEAMCRAFT
®
GENERATOR STYLE
HIGH SPEED CONVECTION STEAMERS
MODEL:
24CGA6.2S
Cleveland Standard Features
■
■
54.5” (1385mm) height to top of upper compartment
(lower height makes maintenance easier by lowering the descal-
ing ports)
■
■
Each compartment has cooking capacity for 3 each
12˝ x 20˝ x 2
1
⁄
2
˝ Steam Table Pans
■
■
Doors hinged left and the controls on the right
■
■
High efficiency independent Power Burner Steam Generators
50,000 BTU's for each compartment
■
■
Each steam-cooking compartment is independently operated
and controlled by a separate stainless steel steam generator,
gas valve, Power On/Off Control Levers and a Exclusive,
Remote Probe-Type Water Level Control
■
■
Easy Access Cleaning Port: Each generator has a deliming port
located on the outside, top of the unit
■
■
Generator Cleaning Light for each compartment warns the oper-
ator to delime generator
■
■
Generator Steam Standby Mode: Holds generator at a
steaming temperature, allows unit to start cooking quickly
■
■
Each compartment has one, 60-Minute Electro-Mechanical
Timer with "SureCook" load compensating feature.
Manual Bypass Switch for constant steaming.
■
■
Durable 14 Gauge, 304 Stainless Steel construction for
compartment door, cooking cavity and steam generator
■
■
Exclusive Gemini Drain/Power Control System:
Manual 1/2 inch "Ball Valve" type drain that controls main power
On/Off and automatically fills generator (located on the control
panel)
■
■
Exclusive Brass Steam Jets distribute steam even throughout
cooking compartment
■
■
Easy, Front -Access Generator Controls comes with a pullout
drawer for simple servicing of unit
■
■
6˝ Stainless Steel Adjustable Legs with Flanged Feet
■
■
Approvals: CSA (AGA, CSA) and U.L/NSF#4
■
■
Compartment Steam Shut-Off Switch when compartment door is
opened
Options & Accessories
❐ Electronic Timer with Compensating Feature (ETC)
❐ On/Off Steam Switch Controls, no timer (MC)
Cleveland
SteamCraft
Gemini
TM
Model 24CGA6.2S, 54.5" high,
Two compartment steamer. Independent steam generators
, 50,000
BTU's input per compartment. "SureCook" electro mechanical timer
with load compensating feature. Gas valve and water level control
system. Exclusive remote probe-type water level controls.
Exclusive Brass “Steam Jet” distribution system. Two-piece free-
floating compartment door. 14 gauge stainless steel cavity and
door. Pullout service drawer for controls and Gemini Drain/Power
Control System.
❐ Propane Gas (PG)
❐ Dissolve
®
Descale Solution, 6 one gallon container w/quart
markings (106174)
❐ Water Filters
Short Form Specifications
SteamCraft
®
Gemini
TM
6
SHORT SERIES PRESSURELESS STEAMER,
TWIN, INDEPENDENT GAS-FIRED GENERATORS
SECT.
IV
PAGE
11
1007
