Cisco 11500 Series User Manual
Page 62
Chapter 2 Cabling the CSS
Cabling the CSS 11501
2-6
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-13884-03
Link /Act
for the Gigabit
Ethernet Port
Green
Off
There is no link.
On
The link exists and
synchronization is achieved.
Blinking
The link is established with
transmit or receive activity.
Table 2-1
CSS 11501 LED Descriptions (continued)
LED Name
Color
State
Indicates
