The Broil pad controls the Broil feature. When broiling, heat radiates downward from the oven broilerforeven coverage. The
Broil feature is preset to start broiling at 550°F however, the Broil feature temperature may be set at any temperature
between400°F and550°F.
The broil pan and broil pan insert used together allows dripping grease to drain and be kept away from the high heat of the
oven broiler. DO NOT use the broil pan without the insert (See Fig. 5; some models). DO NOT cover the broil pan insert
with foil. The exposed grease could catch fire.
Setting Oven Controls
• Setting B roil (G as R ange)
ik WARNING
Should an oven fire occur, leave the oven door closed and turn the oven OFF. If the fire continues, throw
baking soda on the fire or use a fire extinguisher. DO NOT put water or flour on the fire. Flour may be explosive and water
can cause a grease fire to spread and cause personal injury.
INSTRUCTIONS
PRESS
To set the oven to broil at the default setting (550°F):
1. Place the broiler pan insert on the broiler pan (some models).
Then place the food on the broiler pan insert. DO NOT use the
broiler pan without the insert. DO NOT cover the broiler insert
with foil. The exposed grease could ignite.
2. Arrange the interior oven rack and place the broiler pan on the
rack. Be sure to center the broiler pan directly under the broiler
burner. Close the oven door. For optimum browning,
preheat broil burner for 3 - 4 minutes before adding food.
DISPLAY
■ j n
ccn°
■ J U J J U
Fig. 1
3 0
550‘D
3.
4.
5.
6
.
Press Broil . "BROIL" will flash and "550°" will appear (Fig. 1 ).
If a lower broil temperature is desired (minimum broil
temperature setting is 400°F), press the desired temperature
before continuing to step 5.
Press . The oven will begin to broil. "BROIL" and "550°"
will appear in the display (Fig. 2).
Broil on one side until food is browned; turn and cook on the
second side. Season and serve. Note: Aiways pull the rack out
to the stop position before turning or removing food.
Fig.3
7. To cancel broiling or if finished broiling press (Fig. 3).
Recommended Broiling Times
Use the following table for approximate broiling times. Increase or decrease broiling times, or
move the broiling pan to a different rack position to suit for doneness. If the food you are
broiling is not iisted in the table, follow the instructions provided in your cookbook and watch
the item closely.
O
O
o
m
Fig. 4
Broiling Table (Refer to Fig. 4)
Food
Rack
Temp
Cook Time
Item
Position
Setting
1 s t side
2nd side
Doneness
Steak 1" thick
5th or 6th
550° F
8:00
6:00
M edium
5th or 6th
550° F
10:00
8:00
M edium -W ell
Pork C hops 3/4" thick
5th
550° F
12:00
8:00
W ell
C hicken - Bone In
4rd
450° F
25:00
15:00
W ell
C hicken - Boneless
5th
450° F
10:00
8:00
W ell
Fish
5th
500° F
as directed
as directed
W ell
Shrim p
4rd
550° F
as directed
as directed
W ell
H am burger 3/4" thick
6th
550° F
12:00
10:00
W ell
5th
550° F
14:00
12:00
W ell
21
