KENMORE “3000” CENTRAL HUMIDIFIER
MODEL NO. 303.9380612
REPAIR PARTS
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1
21567101
Plenum Stiffener
25
03029401
Locknut
2
STD 610803
Screw (11 Req.)
26
21569101
Float Valve Body
(No. 8A
X
3/8" Slotted)
27
28110201
Pivot Pin
3
21568601
Upper Case
28
22513801
Float Arm
4
21595401
Rod
29
28110101
Float Valve Button (1 Req.)
5
28126101
Switch
30
42063901
Float
6
21568301
Switch Plate
31
21568101
Reservoir
7
21572501
Conduit Box
32
STD 575026
Brass Compression Sleeve 1/4"
8
STD 541010
Nut (2 Req.) (No. 10-24)
33
35586301
Lower Case
9
030060-04
Screw (Ground)
34
21591001
Reservoir Divider Assy.
(No. 10-24
X
1/4" Hex &
(Includes Key Nos. 35 & 36)
Slotted Head)
35
21590701
Panel Clip
10
28112004
Strain Relief
36
21567702
Reservoir Divider
11
STD 511003
Screw (No. 10-24 x 3/8"
37
35586101
Media Wheel & Gear
Cross Recess)
(Includes Key No. 39)
12
22515601
Conduit Box Cover
38
35569203
Media Pad (42-9336)
13
STD 610803
Screw (2 Req.) (No. 8B x 3/8"
39
21575001
Clip (3 Req.)
Cross Recess)
40
35587001
Blower Wheel
14
21570101
Front Panel
41
03013712
(Nut (4 Req.) (No. 8-32)
15
35561801
Saddle Valve
42
28084602
Grommet (4 Req.)
(Includes Key Nos. 23 & 32)
43
28108701
Eyelet
16
21582703
Plastic Supply Tubing (1/4" x 10 ft.)
44
21569801
Fan Blade
17
STD 541006
Nut (2 Req.) (No. 6-32)
45
35586201
Blower Motor
18
21568401
Media Motor Panel
(Includes Key No. 44)
19
35585901
Media Motor
46
STD 375005
Wire Nut (2 Req.)
(Includes Key Nos. 17 & 20)
47
03021303
Capped Fastener
20
STD 510603
Screw (2 Req.) (No. 6-32 x 3/8"
48
21551001
Wire Clip
Cross Recess)
49
28154601
Wire Harness
21
21572701
Plug, Quick Disconnect
50
41067501
Brass Insert (2 Req.)
22
21586101
Socket, Quick Disconnect
51
03028603
Screw (2 Req.)
23
STD 575025
Brass Compression Nut
52
21568201
Optional Accessory Reservoir
24
35561102
Float Valve
Liner
(Includes Key Nos. 25 - 30)
21595801
Owner’s Manual
A
21593601
Humidistat
THIS IS A PARTS LIST, NOT A PACKING LIST.
*Not Shown
