REFRIGERATOR INSTALLATION
HOW TO REMOVE AND INSTALL THE
FREEZER DRAWER (coni)
2. Installing Freezer Drawer
• Fully extend the rails by grasping the center bar
with both hands and pulling straight out.
' Hook door supports © into rail tabs i
sides.
on both
Lower door into final position and tighten the
screws
(3).
With the drawer pulled out to full extension, insert
the lower basket @ in the rail assembly.
A
WARNING:
If the Durábase divider is removed,
there is enough open space for children or pets to
crawl inside. To prevent accidental child and pet
entrapment or suffocation risk, DO NOT allow
them to touch or go near the freezer drawer.
A
WARNING:
DO NOT step or sit down on freezer
drawer.
16
