Contents for Hardware Pack/NG (Part #P06001015A)
The following table illustrates a breakdown of the hardware pack. It highlights what components are used
in the various stages of assembly.
Ref.
Component
Qty.
Purpose of Components
H001
3/8’'x85mm Wheel Bolt
2
Install Wheels To Cart Legs
H002
Spring Washer
2
H039
3/8" Nut
2
H019
1/4"x2" Pattern Head Screw
8
Attaches Cart Legs To Bottom Shelf
H017
1/4"x1/2" Pattern Head Screw
4
Attaches Rear Panel To Cart
H019
1/4"x2" Pattern Head Screw
4
Attaches Door Bracket To Cart
H017
1/4"x1/2" Pattern Head Screw
4
Attaches Door Stops To Cart
H006
1/4"x5/8" Partly-Threaded Bolt
4
Attaches Doors To Cart
H017
1/4"x1/2" Pattern Head Screw
4
Attaches Cart Spice Basket To Door
H022
M4x5mm Pattern Head Screw
4
Attaches Door Handles To Doors
H017
1/4"x1/2" Pattern Head Screw
4
Attaches Grill Head To Cart
H018
1/4"x3/4" Pattern Head Screw
8
Attaches Side Shelf and Side Burner To The
Grill Head
P05301001A
AA Battery
2
Powers The Electric Ignitor
P00215019H
Door Handle
2
Attaches To Front Doors
P05318022B
Magnetic Door Stop
2
Attaches To Cart
P03412331C
Control Knob
1
Install To Side Burner Valve Stem
P05501010B
Cotter Pin
1
Secure To Side burner
H025
M4x8mm Pattern Head Screw
2
Attaches To Side Burner Valve Bracket
H027
M4 Plain Washer
2
Attaches To Side Burner Valve Bracket
P05515101L
No.17 Customized Wrench
1
Tighten Caster & Wheel Bolt
P05313023B
Manual Lighting Stick
1
Attaches To Outside Bowl Panel - Left
H025
M4x8mm Pattern Head Screw
1
Attaches To Outside Bowl Panel - Left
P05515102K
Tightening Too!
1
Allows you to tighten Pattern Head Thumb Screws
as needed
Customer Service Helpline: If you have questions about assembly or grill operation, or if there are
damaged or missing parts when you unpack this unit from the shipping box, call us Sam - 8pm CST,
Monday through Friday at; 1-888-317-7642
