Kenmore 141.17337 - Manual (Page 11)

Model 15337 & 17337 Parts List
REF# DESCRIPTION PART# QTY
1. Stainless Steel Lid P00117336A 1
2. Lid Side Panel - Left P00105227P 1
3. Lid Side Panel - Right P00106227P 1
4. Temperature Gauge P00607153A 1
5. Lid Handle P00205030B 1
6. Heat-Insulating Spacer P06801002A 2
7. Name Plate P00410037C 1
8. Secondary Cooking Rack - Porcelain P01508026E 1
9. Cooking Grid - Porcelain P01615027E 3
10. Flame Tamer - Porcelain P01705016E 3
11. Main Burner w. Heat-Insulating Ring P02001006C 6
11a. Air Shutter for Main Burner (NG only) P05524060C 6
12. Main Burner Bracket P02206251B 1
13.
14.
Gas Collector Box w. Electrode
Ignition Wire Set
P02605013C 3
LPG P02615050A 1
NG P02615065A 1
15. Electric Ignitor - 4 Ports P02502024C 1
16. Electric Ignitor - 2 Ports P02502012C 1
17. Smoker Drawer Bracket P06708012D 1
18. Smoker Drawer P06701003A 1
19. Bowl Panel - Left P00720271A 1
20. Outside Bowl Panel - Left P00742275B 1
21. Bowl Panel - Right P00721271A 1
22. Outside Bowl Panel - Right P00743275B 1
23. Bowl Panel - Front P00738284A 1
24. Bowl Panel - Rear P00725284A 1
25. Wind Shield P00737285B 1
26. Reinforcing-Bracket for Grill Bowl P03315023D 1
27. Grease Draining Tray P02708261A 1
28. Heat Shield for Grease Tray P06903013A 1
29. Grease Receptacle P02701074A 1
30. Gas Manifold Assembly - LPG Y0060094 1
31. Gas Manifold Assembly - NG Y0060095 1
32. Protective Pad - Heat Resistant P05518001I 2
33. pogtrol Panel
P02910261N 1
NG^ P02910261T 1
34. Decorative Front Cover P07508006A 1
35. Control Knob P03412331C 7
36. Back Burner Assembly P02007049D 1
37.
38.
Electrode for Back Burner
Orifice for Back Burner
P02614006B 1
LPG P06509010A 1
NG P06509016A 1
39. Extension Tube for Back Burner P03717030A 1
40. Control Knob for Back Burner P03412341C 1
41. Side Shelf - Left P01102002C 1
42a. Side Burner Frame (LPG only) P01104027C 1
42b. Side Burner Frame {NG only) P01104004C 1
43a. Bottom Shelf (LPG only) P01005024D 1
43b. Bottom Shelf (NG only)
11
P01005032D 1
