6. For Natural Gas grills:
Connect the Ignition Wire terminal from Side Burner
with Ihe otiier from Grill Head. See Fig. 8d. Bind
the connected Ignition Wires, and Connection
Tube together using the supplied Fastening Band.
The gap between tiie Side Burner Electrode Tip
and the Side Burner Port should be approximately
1/8"~3/16". See Fig. Se.lf the gap is wider than
3/16", use a pair of long nose pliers and gently
bend the Electrode Tip toward the Burner.
Slide the 5 Tool Hooks onto the Tool Holder with
hooks facing the grill Head. Attach Tool Holder
to left side of Side Shelf and secure firmly using
2 of the M5x8mm Pattern Head Screws and
washers supplied. See Fig. 8f.
Assembly Tips
When you have finished assembling your
grill we strongly urge that all Pattern
Head Thumb Screws be tightened, either
with the supplied Tightening Tool or a
#2 Phillips Head Screwdriver.
Figure 8d (Natural gas model only)
Tightening Tool
Ref. # P05515102K
9. For Natural Gas grills:
Connect the hose end of the 12’ Natural Gas
Hose to the vertical fitting as shown in Fig.
8g. Al so read the natural gas safety instruc
tions. {on page 4)
Figure 8g (Natural gas model only)
Figure 8e
iy8.._3yie"
BURNER
GAS VALVE FOR
Figure 8f
TOOL HOOK
18
