Step 3: Connect External Devices
Connect the monitor, mouse, keyboard, and network cables.
Rear Panel Connectors (Arrangement of connectors may vary
by model.)
1
Power Cord Connector
2
Voltage Select Switch
3
Mouse Connector
4
Keyboard Connector
5
Universal Serial Bus (USB)
Connectors
6
Serial Connector
7
Parallel Port Connector
8
Monitor Connector
9
Headphone/Line-out
Connector
-
Audio/Line-in Connector
q
Microphone connector
w
Gameport connector
CAUTION: Do not add optional hardware devices to your personal
computer until the operating system is successfully installed. Doing so
may cause errors and may prevent the operating system from installing
properly.
Compaq Evo D300v User’s Guide
1-3
